caseih magnum 315
![]() | 2011 - 2013
Magnum系列行作拖拉机 | 2011 - 2013 | Magnum 系列 | 行作物拖拉机 |
---|---|---|---|---|
2011 - 2013 | ||||
Magnum 系列 | ||||
行作物拖拉机 |
2011 - 2013 | |
---|---|
Magnum 系列 | |
行作物拖拉机 |
生产 | |
---|---|
制造商 | CaseIH(CNH 旗下的一部分) |
行作物拖拉机 | |
在美国威斯康星州拉辛建造 |
CaseIH Magnum 315 发动机 | |
---|---|
FPT 8.7L 6缸柴油机 | |
燃油箱 | 168 加仑
635.9 升 |
废气处理液 (DEF) | 23.6 加仑
89.3 升 |
发动机详情... ![]() |
CaseIH Magnum 315 变速箱 | |
---|---|
19速全功率换挡 | |
18速全功率换挡 | |
23速爬行 | |
无级变速器 | |
变速箱详情... ![]() |
CaseIH Magnum 315 Power | |
---|---|
发动机 (毛) | 312 马力
232.7 千瓦 |
发动机 (最大) | 347 马力
258.8 千瓦 |
动力输出(声称) | 265 马力
197.6 千瓦 |
牵引钩(测试) | 231.39 马力
172.5 千瓦 |
动力输出 (已测试) | 315.72 马力
235.4 千瓦 |
性能测试详情... ![]() |
机械的 | |
---|---|
四轮驱动 | |
助力转向 | |
Magnum Surveyor 标准驾驶室。可选驾驶室悬挂。 |
液压 | |
---|---|
类型 | 压力-流量补偿 |
后阀 | 4到6 |
总流量 | 44 加仑/分钟
166.5 升/分钟 |
空白 | 59 加仑/分钟 (可选)
223.3 升/分钟 |
空白 | 75 加仑/分钟(可选)
283.9 升/分钟 |
拖拉机挂钩 | |
---|---|
后类型 | 3/3N |
空白 | 4N/3 (可选) |
后举升 | 14,375 磅 (3/3N 109厘米链条)
6520 千克 |
空白 | 16,375 磅(3/3N 96厘米链接)
7427 公斤 |
空白 | 15,400 磅(3/3N 109 厘米连杆可选)
6985 公斤 |
空白 | 17,400 磅(3/3N 96厘米链条可选)
7892 公斤 |
空白 | 17,400 磅 (4N/3 109厘米链条)
7892 公斤 |
空白 | 19,400 磅 (4N/3 96厘米链条)
8799 千克 |
前挂 | 可选 |
前提升 | 9,426 磅
4275 公斤 |
动力输出 (PTO) | |
---|---|
后 PTO | 独立 |
后部动力输出类型 | 1000 (1.75) |
空白 | 540/1000 (1.375)可选 |
发动机转速 | 540@1804 |
空白 | 1000@1804 |
前置动力输出 | 独立可选 |
前置 PTO 类型 | 1000 (1.375) |
尺寸与轮胎 | |
---|---|
轮距 | 120英寸
304厘米 |
重量 | 27,800 磅
12610 公斤 |
完全尺寸和轮胎... ![]() |
Magnum 315 序列号位置 | |
---|---|
![]() | |
拖拉机车架右侧,前轴上方有序列号牌。 |
电气 | |
---|---|
地面 | 负面 |
充电系统 | 发电机 |
充电电流 | 二百 |
电池 | 2 |
电池电压 | 12 |
参考文献 | |
---|---|
![]() | |
Magnum系列拖拉机于2011年由CaseIH出版 | |
Magnum系列拖拉机新机型2011年预览,由CaseIH于2010年发布 |
