caseih steiger 330
 | 2007 - 2008
Four-wheel Drive (4WD) tractor | 2007 - 2008 | Four-wheel Drive (4WD) tractor |
|---|---|---|---|
2007 - 2008 | |||
Four-wheel Drive (4WD) tractor | |||
2007 - 2008 | |
|---|---|
Four-wheel Drive (4WD) tractor |
Production | |
|---|---|
Manufacturer | CaseIH |
Four-wheel Drive (4WD) tractor | |
Built in Fargo, North Dakota, USA | |
CaseIH Steiger 330 Engine | |
|---|---|
CNH 8.9L 6-cyl diesel | |
Fuel tank | 200 gal
757.0 L |
Engine details ...  | |
CaseIH Steiger 330 Transmission | |
|---|---|
16-speed full power shift | |
Transmission details ...  |
CaseIH Steiger 330 Power | |
|---|---|
Engine | 330 hp
246.1 kW |
PTO (claimed) | 269 hp
200.6 kW |
Drawbar (tested) | 258.63 hp
192.9 kW |
PTO (tested) | 323.31 hp
241.1 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Four-wheel drive | |
Final drives | inboard planetary |
Articulated power steering | |
Integrated hydraulic wet disc brakes | |
Cab standard | |
Hydraulics | |
|---|---|
Type | PFC |
Pump flow | 40 gpm
151.4 lpm |
| 55 gpm*Optional high capacity pump.
208.2 lpm |
| 90 gpm*Optional TwinFlow
340.7 lpm |
Tractor hitch | |
|---|---|
Rear Type | IVN |
Rear lift (at 24"/610mm) | 15669 lbs
7107 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent OptOptional |
Rear PTO Type | 1000 |
Dimensions & Tires | |
|---|---|
Wheelbase | 139 inches
353 cm |
Weight | 32295 lbs
14649 kg |
Front tire | 480/80R46 |
Rear tire | 480/80R46 |
Full dimensions and tires ...  | |
