ford new holland 7710
 | 1982 - 1990
Row-Crop tractor | 1982 - 1990 | Row-Crop tractor |
|---|---|---|---|
1982 - 1990 | |||
Row-Crop tractor | |||
1982 - 1990 | |
|---|---|
Row-Crop tractor |
Note: the Ford-New Holland model 7710 is the same as the Ford 7710. The following data is from the 7710 listing. |
|---|
Tractor Tests | |
|---|---|
NTTL 1432: diesel 16/4 4WD | |
NTTL 1433: diesel 16/8 powershift 2WD |
Nebraska Tractor Test 1432 | ||
|---|---|---|
 | | |
| ||
|
|---|
Nebraska Tractor Test 1432 | |
|---|---|
Diesel 16/4 4WD
April 14 - May 10, 1982
Link: Nebraska Tractor Test 1432 file | |
PTO performance | |
Power at rated engine speed | 86.95 hp
64.8 kW |
Fuel use | 5.6 gal/hour
21.2 l/hour |
Power at rated PTO speed | 86.79 hp
64.7 kW |
Fuel use | 1.0 gal/hour
3.8 l/hour |
Drawbar performance | |
Max power | 74.08 hp
55.2 kW |
Fuel use | 5.5 gal/hour
20.8 l/hour |
Gear 6L used for power test. | |
Max pull | 8,804 lbs
3993 kg |
Gear 3L used for pull test. | |
Nebraska Tractor Test 1433 | ||
|---|---|---|
 | | |
| ||
|
|---|
Nebraska Tractor Test 1433 | |
|---|---|
Diesel 16/8 powershift 2WD
April 2 - May 3, 1982
Link: Nebraska Tractor Test 1433 file | |
PTO performance | |
Power at rated engine speed | 86.62 hp
64.6 kW |
Fuel use | 5.5 gal/hour
20.8 l/hour |
Power at rated PTO speed | 86.55 hp
64.5 kW |
Fuel use | 5.5 gal/hour
20.8 l/hour |
Drawbar performance | |
Max power | 72.33 hp
53.9 kW |
Fuel use | 5.3 gal/hour
20.1 l/hour |
Gear 6L used for power test. | |
Max pull | 8,638 lbs
3918 kg |
Gear 3L used for pull test. | |
