hart parr row crop 18 27
![]() | 1930 - 1935
行作物拖拉机 | 1930 - 1935 | 行作物拖拉机 |
|---|---|---|---|
1930 - 1935 | |||
行作物拖拉机 | |||
1930 - 1935 | |
|---|---|
行作物拖拉机 |
生产 | |
|---|---|
制造商 | 哈特-帕尔(奥利弗的一部分) |
行作物拖拉机 | |
在美国爱荷华州查尔斯城建造 | |
1930年推出,奥利弗哈特-帕尔排灌拖拉机最初的两年采用了单个前轮。1931年,设计改为使用两个前轮。 | |
型号 | |
|---|---|
18-27 | 行作物 |
18-28 | 标准 |
哈特-帕尔排耕18-27发动机 | |
|---|---|
奥利弗 4.6L 4缸煤油 | |
发动机详情... |
哈特-帕尔行作物18-27变速箱 | |
|---|---|
3档变速器 | |
变速箱详情... |
哈特-帕尔排式耕作18-27马力 | |
|---|---|
牵引钩(声明) | 18 马力
13.4 千瓦 |
皮带(声明) | 27 马力
20.1 千瓦 |
犁 | 2-3 (14 英寸) |
牵引钩(测试) | 18.10 马力
13.5 千瓦 |
皮带(已测试) | 29.72 马力
22.2 千瓦 |
性能测试详情... | |
机械的 | |
|---|---|
两轮驱动 | |
最终驱动 | 锥齿轮 |
手动转向 | |
打开操作员站位。 | |
照片 | |
|---|---|
![]() | |
哈特-帕尔排灌18-27照片... |
尺寸与轮胎 | |
|---|---|
重量 | 3500 磅
1587 公斤 |
完全尺寸和轮胎... | |
皮带轮 | |
|---|---|
直径 | 14.5 英寸
36 厘米 |
宽度 | 7.5 英寸
19 厘米 |
转速 | 七百 |
速度 | 800米/分钟
2610英尺/分钟 |
