sabre lawn tractors 1438hs
 | 1999 - 2001
Lawn tractor | 1999 - 2001 | Lawn tractor |
|---|---|---|---|
1999 - 2001 | |||
Lawn tractor | |||
1999 - 2001 | |
|---|---|
Lawn tractor |
Production | |
|---|---|
Manufacturer | Sabre (a part of John Deere) |
Lawn tractor | |
Built in Greeneville, Tennessee, USA | |
Original price was $1,629 in 1999 | |
Sabre 1438HS Engine | |
|---|---|
14.5HP Briggs & Stratton 465cc 1-cyl gasoline | |
Fuel tank | 1.25 gal
4.7 L |
Engine details ...  | |
Sabre 1438HS Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Disc brakes | |
Open operator station. |
Photos | |
|---|---|
 | |
Sabre 1438HS photos...  |
Power Take-off (PTO) | |
|---|---|
Mid PTO | independent |
Clutch | manual |
Dimensions & Tires | |
|---|---|
Wheelbase | 44.7 inches
113 cm |
Weight | 388 lbs
175 kg |
Front tire | 15x6.5-6 |
Rear tire | 20x8-8 |
Full dimensions and tires ...  | |
Sabre 1438HS attachments | |
|---|---|
38" mid-mount mower deck | |
snowblower | |
blade | |
Attachment details ...  |
1438HS Serial Numbers | |
|---|---|
Location: | Serial number decal on top of the rear fender deck, below the seat. |
1999 | GX1438B 010001 |
2000 | GX1438B 020001 |
2001 | GX1438B 120228 |
FAQ: How to read a serial number table. | |
Electrical | |
|---|---|
Ground | negative |
Charging system | unregulated |
Charging amps | 4 |
Battery CCA | 230 |
Battery volts | 12 |
Battery Group | BCI U1 |
References | |
|---|---|
 | |
Lawn and Garden Product Information Handbook published in 2000, by John Deere | |
Lawn and Garden Product Information Handbook published in 2001, by John Deere | |
Commercial & Consumer Equipment Sales Manual published in 1999, by John Deere | |
Grounds Care Equipment Purchasing Guide published in 1999, by John Deere | |
Grounds Care Equipment Purchasing Guide published in 2000, by John Deere | |
Grounds Care Equipment Purchasing Guide published in 2001, by John Deere | |
Operator's Manual Sabre Lawn Tractors 1438GS, 1438HS, 1542HS, 1742GS, 1742HSS and 2046HS (OMGX10782) published in 2000 | |
Sabre Lawn Tractors - Yard Tractors - Garden Tractors published in 1999, by John Deere | |
Sabre Lawn Tractors - Yard Tractors - Garden Tractors published in 2000, by John Deere | |
Sabre Tractors published in 2001, by John Deere |
