agco rt140a
 | 2006 - 2011
RT-A SeriesRow-Crop tractor | 2006 - 2011 | RT-A Series | Row-Crop tractor |
|---|---|---|---|---|
2006 - 2011 | ||||
RT-A Series | ||||
Row-Crop tractor | ||||
2006 - 2011 | |
|---|---|
RT-A Series | |
Row-Crop tractor |
Tractor Tests | |
|---|---|
OECD 2200: diesel 32-speed 4WD | |
OECD 2197: diesel CVT 4WD | |
OECD 2395: diesel 24-speed 4WD | |
OECD 2420: diesel CVT 4WD |
OCED Tractor Test 2200 | ||
|---|---|---|
 | | |
| ||
|
|---|
OCED Tractor Test 2200 | |
|---|---|
Diesel 32-speed 4WD
March 2004 - June 2004,
Link: OCED Tractor Test 2200 file | |
PTO performance | |
Power at rated engine speed | 140.7 hp
104.9 kW |
Fuel use | 8.7 gal/hour
32.9 l/hour |
Power at rated PTO speed | 145.2 hp
108.3 kW |
Fuel use | 8.2 gal/hour
31.0 l/hour |
Drawbar performance | |
Max power | 121.5 hp
90.6 kW |
Fuel use | 8.6 gal/hour
32.6 l/hour |
Gear 4TA used for power test. | |
Max pull | 16,455 lbs
7463 kg |
Gear 1TD used for pull test. | |
OCED Tractor Test 2197 | ||
|---|---|---|
 | | |
| ||
|
|---|
OCED Tractor Test 2197 | |
|---|---|
Diesel CVT 4WD
December 2003 - May 2004,
Link: OCED Tractor Test 2197 file | |
PTO performance | |
Max power | 154.4 hp
115.1 kW |
Fuel use | 8.8 gal/hour
33.3 l/hour |
Power at rated engine speed | 143.2 hp
106.8 kW |
Fuel use | 9.4 gal/hour
35.6 l/hour |
Power at rated PTO speed | 153.1 hp
114.2 kW |
Fuel use | 9.1 gal/hour
34.4 l/hour |
Drawbar performance | |
Max power | 115.1 hp
85.8 kW |
Fuel use | 9.3 gal/hour
35.2 l/hour |
Pull at 7.70 KPH | |
Max pull | 16,690 lbs
7570 kg |
Pull at 3.85 KPH | |
OCED Tractor Test 2395 | ||
|---|---|---|
 | | |
| ||
|
|---|
OCED Tractor Test 2395 | |
|---|---|
Diesel 24-speed 4WD
August 2007 - October 2007,
Link: OCED Tractor Test 2395 file | |
PTO performance | |
Power at rated engine speed | 153.8 hp
114.7 kW |
Fuel use | 9.5 gal/hour
36.0 l/hour |
Power at rated PTO speed | 180.4 hp
134.5 kW |
Fuel use | 10.1 gal/hour
38.2 l/hour |
Drawbar performance | |
Max power | 127.7 hp
95.2 kW |
Fuel use | 8.9 gal/hour
33.7 l/hour |
Pull at 10.50 KPH | |
Max pull | 19,920 lbs
9035 kg |
Pull at 2.11 KPH | |
OCED Tractor Test 2420 | ||
|---|---|---|
 | | |
| ||
|
|---|
OCED Tractor Test 2420 | |
|---|---|
Diesel CVT 4WD
June 2007 - September 2007,
Link: OCED Tractor Test 2420 file | |
PTO performance | |
Max power | 179.7 hp
134.0 kW |
Fuel use | 9.7 gal/hour
36.7 l/hour |
Power at rated engine speed | 153.8 hp
114.7 kW |
Fuel use | 9.2 gal/hour
34.8 l/hour |
Power at rated PTO speed | 174.3 hp
130.0 kW |
Fuel use | 9.7 gal/hour
36.7 l/hour |
Drawbar performance | |
Max power | 111.4 hp
83.1 kW |
Fuel use | 8.4 gal/hour
31.8 l/hour |
Pull at 8.21 KPH | |
Max pull | 19,490 lbs
8840 kg |
Pull at 2.45 KPH | |
