agco allis 9655
 | 1994 - 1998
9600 SeriesRow-Crop tractor | 1994 - 1998 | 9600 Series | Row-Crop tractor |
|---|---|---|---|---|
1994 - 1998 | ||||
9600 Series | ||||
Row-Crop tractor | ||||
1994 - 1998 | |
|---|---|
9600 Series | |
Row-Crop tractor |
OCED Tractor Test 1698 | ||
|---|---|---|
 | | |
| ||
|
|---|
OCED Tractor Test 1698 | |
|---|---|
Diesel 18-speed 4WD
September 6 - 22, 1995
Link: OCED Tractor Test 1698 file | |
PTO performance | |
Max power | 168.70 hp
125.8 kW |
Fuel use | 9.8 gal/hour
37.1 l/hour |
Power at rated engine speed | 155.66 hp
116.1 kW |
Fuel use | 9.8 gal/hour
37.1 l/hour |
Drawbar performance | |
Max power | 135.53 hp
101.1 kW |
Fuel use | 9.8 gal/hour
37.1 l/hour |
Gear 11 used for power test. | |
Max pull | 16739 lbs
7592 kg |
Gear 5 used for pull test. | |
