AGCO 1606H
The AGCO 1606H is a tractor produced by Agco Lawn Tractors. It is equipped with a 458 cc 28 ci engine. The listed engine power is Gasoline (gross): 16 hp / 11.9 kW. Transmission: Tuff Torq K57. Operating weight: 130 lbs 58 kg.
Engine Power
Gasoline (gross): 16 hp / 11.9 kW
Fuel & Capacities
4 gal
15.1 L
Transmission
Tuff Torq K57
Operating Weight
130 lbs
58 kg
Overview
 | 2003 - 2004
1600 SeriesLawn tractorSimplicity built
1600 Series
Lawn tractor
Simplicity built |
|---|
Note: the AGCO model 1606H is the same as the Simplicity Broadmoor 16H. The following data is from the Broadmoor 16H listing. |
|---|
Production | |
|---|---|
Distributor | AGCO |
Manufacturer | Simplicity |
Lawn tractor | |
Original price was $3,525 in 2003 | |
AGCO 1606H Engine | |
|---|---|
16HP Kohler 458cc 1-cyl gasoline | |
Fuel tank | 4 gal
15.1 L |
Engine details ...  | |
AGCO 1606H Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering |
Power Take-off (PTO) | |
|---|---|
Mid PTO | independent |
Clutch | electric |
Dimensions & Tires | |
|---|---|
Wheelbase | 52 inches
132 cm |
Weight | 690 lbs
312 kg |
Front tire | 15x6.0-6 |
Rear tire | 20x10-10 |
Full dimensions and tires ...  | |
References | |
|---|---|
 | |
Lawn & Garden Equipment published in 2004, by AGCO |
Engine
Note: the AGCO model 1606H is the same as the Simplicity Broadmoor 16H. The following data is from the Broadmoor 16H listing. |
|---|
Engine Detail — 458 cc / 28 ci Gasoline
Manufacturer | Kohler CV460 |
Fuel Type | Gasoline |
Configuration | 1-cylinder, air-cooled vertical-shaft |
Displacement | 458 cc
28 ci |
Bore/Stroke | 3.43x3.03 inches
87 x 77 mm |
Power (gross) | 16 hp
11.9 kW |
Starter | electric |
Starter volts | 12 |
Transmission
Note: the AGCO model 1606H is the same as the Simplicity Broadmoor 16H. The following data is from the Broadmoor 16H listing. |
|---|
Transmission — Tuff Torq K57
Transmission | Tuff Torq K57 |
Type | belt-driven hydrostatic |
Gears | infinite forward and reverse |
 | |
Dimensions
Note: the AGCO model 1606H is the same as the Simplicity Broadmoor 16H. The following data is from the Broadmoor 16H listing. |
|---|
AGCO 1606H Tires | |
|---|---|
Lawn/turf front | 15x6.0-6 |
Lawn/turf rear | 20x10-10 |
Dimensions | |
|---|---|
Wheelbase | 52 inches
132 cm |
Length | 70 inches
177 cm |
Width | 37 inches
93 cm |
Height | 43 inches
109 cm |
Weight | 690 lbs
312 kg |
Attachments
Note: the AGCO model 1606H is the same as the Simplicity Broadmoor 16H. The following data is from the Broadmoor 16H listing. |
|---|
Attachment overview | |
|---|---|
44" mid-mount mower deck | |
Snowblower | |
Blade |
44" Mower deck | |
|---|---|
Type | mid-mount Simplicity 1694037 |
3-blade | |
Cutting width | 44 inches
111 cm |
Weight | 130 lbs
58 kg |
Overall width | 56 inches
142 cm |
Cut height | 1.25 to 3.75 inch
3 to 9 cm |
Recommended Implements & Sizing Guide
Engineering recommendations for Agco Lawn Tractors AGCO 1606H based on its 16 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 1 to 2 Bottom (12")1 - 2 铧 (30 cm) | Light Duty | Ideal for garden plots and light sandy soil. |
Rotary Cutter / MowerMowing & Clearing | 4 ft (48 in)1.2 m | Light Duty | Pasture clipping and light brush under 1" diameter. |
Rotary TillerSeedbed Prep | 42 to 48 in105 - 120 cm | Light Duty | Covers compact tractor tire width. |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Agco Lawn Tractors AGCO 1606H.
Estimated Continuous Field Runtime: 4.8 hrs
Approximately 4.8 hours of continuous field operation at ~75% rated power on a full tank (4 gal / 15.1 L).
Estimated 75% Load Fuel Burn~0.8 gal/hr (3.1 L/hr)
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Agco Lawn Tractors AGCO 1606H Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Agco Lawn Tractors AGCO 1606H.
Converted Equivalents:
Horsepower (HP)16 hp
Kilowatts (kW)11.9 kW
Metric Horsepower (PS / CV)16.2 PS
Direct Competitor Comparison
Compare AGCO 1606H against same-era industry alternatives in the same horsepower class.
Current Model
Agco Lawn Tractors
AGCO 1606H
Engine Power:Gasoline (gross): 16 hp / 11.9 kW
★ Baseline Reference
