AGCO 1716
The AGCO 1716 is a tractor produced by Agco Lawn Tractors. It is equipped with a 480 cc 29.3 ci engine. The listed engine power is Gasoline (gross): 16 hp / 11.9 kW. Transmission: Tuff Torq K210-A. Operating weight: 670 lbs 303 kg.
Engine Power
Gasoline (gross): 16 hp / 11.9 kW
Fuel & Capacities
4 gal (early)
15.1 L
Transmission
Tuff Torq K210-A
Operating Weight
670 lbs
303 kg
Overview
 | 1992 - 1998
1700 SeriesGarden tractorSimplicity built
1700 Series
Garden tractor
Simplicity built |
|---|
Series map: 17141716171714.0hp16.0hp17.0hp
Note: the AGCO model 1716 is the same as the Simplicity Landlord 16. The following data is from the Landlord 16 listing. |
Production | |
|---|---|
Distributor | AGCO |
Manufacturer | Simplicity |
Garden tractor | |
Built in Port Washington, Wisconsin, USA | |
Original price | $5,250 (1993 hydro ) |
$4,500 (1994 gear ) | |
$5,350 (1994 hydro ) | |
Variants | |
|---|---|
Landlord 16 | similar Simplicity model |
AGCO 1716 Engine | |
|---|---|
16HP Vanguard 480cc 2-cyl gasoline | |
Fuel tank | 4 gal (early)
15.1 L |
5 gal (late)
18.9 L | |
Engine details ...  | |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Open operator station. |
Power Take-off (PTO) | |
|---|---|
Mid PTO | independent |
Clutch | electro-magnetic |
Dimensions & Tires | |
|---|---|
Wheelbase | 51.5 inches
130 cm |
Weight | 670 lbs
303 kg |
Front tire | 16x6.50-8 |
Rear tire | 23x10.50-12 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 16 |
Battery CCA | 340 |
Battery volts | 12 |
References | |
|---|---|
 | |
Operator's Manual 1700 Series (1707352) published in 1992 | |
Operator's Manual 1700 Series (1714300) published in 1996 | |
Lawn & Garden Tractors published in 1993, by AGCO Allis | |
Lawn & Garden Tractors published in 1994, by AGCO Allis | |
1994 Price List published in 1993, by Simplicity | |
1996 Dealer Prduct Guide published by Simplicity | |
1997 Spring Product Guide published in 1996, by Simplicity |
Engine
Series map: 17141716171714.0hp16.0hp17.0hp
Note: the AGCO model 1716 is the same as the Simplicity Landlord 16. The following data is from the Landlord 16 listing. |
Engine Detail — 480 cc / 29.3 ci Gasoline
Manufacturer | Vanguard 303777 |
Fuel Type | Gasoline |
Configuration | 2-cylinder, air-cooled vertical-shaft V-Twin |
Displacement | 480 cc
29.3 ci |
Bore/Stroke | 2.68x2.60 inches
68 x 66 mm |
Power (gross) | 16 hp
11.9 kW |
Starter | electric |
Starter volts | 12 |
Transmission
Series map: 17141716171714.0hp16.0hp17.0hp
Note: the AGCO model 1716 is the same as the Simplicity Landlord 16. The following data is from the Landlord 16 listing. |
Transmission options | |
|---|---|
hydrostatic | |
6-speed gear |
Transmission — Tuff Torq K215-A
Transmission | Tuff Torq K215-A |
Type | belt-driven hydrostatic |
Gears | infinite forward and reverse |
Oil capacity | 2.8 qts
2.6 L |
 | |
Transmission — Tuff Torq K210-A
Transmission | Tuff Torq K210-A |
Type | belt-driven gear |
Gears | 6 forward and 1 reverse |
Oil capacity | 3.875 qts
3.7 L |
The Landlord 16G became available in 1994 when it replaced the 14G. | |
 | |
Dimensions
Series map: 17141716171714.0hp16.0hp17.0hp
Note: the AGCO model 1716 is the same as the Simplicity Landlord 16. The following data is from the Landlord 16 listing. |
AGCO 1716 Tires | |
|---|---|
Lawn/turf front | 16x6.50-8 |
Lawn/turf rear | 23x10.50-12 |
Dimensions | |
|---|---|
Wheelbase | 51.5 inches
130 cm |
Length | 72 inches
182 cm |
Width | 39 inches
99 cm |
Height (steering wheel) | 42.5 inches
107 cm |
Height (hood) | 36 inches
91 cm |
Shipping weight | 670 lbs
303 kg |
Attachments
Series map: 17141716171714.0hp16.0hp17.0hp
Note: the AGCO model 1716 is the same as the Simplicity Landlord 16. The following data is from the Landlord 16 listing. |
Attachment overview | |
|---|---|
44" mid-mount mower deck | |
50" mid-mount mower deck | |
Snowblower | |
Blade | |
Garden tractors are capable of using tillers, plows, or other ground-engaging attachments. TractorData does not list details of these attachments. |
Photos
AGCO 1716 tractor photo
Recommended Implements & Sizing Guide
Engineering recommendations for Agco Lawn Tractors AGCO 1716 based on its 16 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 1 to 2 Bottom (12")1 - 2 铧 (30 cm) | Light Duty | Ideal for garden plots and light sandy soil. |
Rotary Cutter / MowerMowing & Clearing | 4 ft (48 in)1.2 m | Light Duty | Pasture clipping and light brush under 1" diameter. |
Rotary TillerSeedbed Prep | 42 to 48 in105 - 120 cm | Light Duty | Covers compact tractor tire width. |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Agco Lawn Tractors AGCO 1716.
Estimated Continuous Field Runtime: 4.8 hrs
Approximately 4.8 hours of continuous field operation at ~75% rated power on a full tank (4 gal / 15.1 L).
Estimated 75% Load Fuel Burn~0.8 gal/hr (3.1 L/hr)
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Agco Lawn Tractors AGCO 1716 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Agco Lawn Tractors AGCO 1716.
Converted Equivalents:
Horsepower (HP)16 hp
Kilowatts (kW)11.9 kW
Metric Horsepower (PS / CV)16.2 PS
