allis chalmers 5040
 | 1976 - 1980
Utility tractorUTB/Universal built | 1976 - 1980 | Utility tractor | UTB/Universal built |
|---|---|---|---|---|
1976 - 1980 | ||||
Utility tractor | ||||
UTB/Universal built | ||||
1976 - 1980 | |
|---|---|
Utility tractor | |
UTB/Universal built |
Transmission options | |
|---|---|
6-speed | |
8-speed | |
12-speed creeper |
Transmission | |
|---|---|
Transmission | partially synchronized |
Gears | 6 forward and 2 reverse |
Clutch | 254mm dry disc |
Oil capacity | 19 qts
18.0 L |
Three gears, plus reverse, in two ranges. Synchronized shifting between the top two gears (2/3 and 5/6). Used from 1976 to 1978. | |
Speeds | |
|---|---|
With 13.6-28 rear tires. | |
 |
Transmission | |
|---|---|
Transmission | partially synchronized |
Gears | 8 forward and 2 reverse |
Clutch | 279mm dry disc |
Oil capacity | 19 qts
18.0 L |
Four gears, plus reverse, in two ranges. Synchronized shifting between the top two gears (3/4 and 7/8). | |
Speeds | |
|---|---|
With 13.6-28 rear tires. | |
 |
Transmission | |
|---|---|
Type | creeper |
Gears | 12 forward and 3 reverse |
Adds an additional creeper range to the standard transmission. Creeper was available for either the 3-speed (early) or 4-speed (late) gearbox. On the early transmission, the third gear omitted. | |
Speeds | |
|---|---|
 |
