B.F. Avery V

The B.F. Avery V is a tractor produced by B F Avery. It is equipped with a 64.9 ci 1.1 L engine. The rated power output is 9 hp 6.7 kW. Transmission: 3 forward and 1 reverse. Operating weight: 1612 lbs 731 kg.

Overview

	1946 - 1951 Row-Crop tractor
1946 - 1951
Row-Crop tractor

Production
Manufacturer	B.F. Avery
Row-Crop tractor
Built in Louisville, Kentucky, USA

B.F. Avery V Engine
Hercules 1.1L 4-cyl gasoline
Fuel tank	1.75 gal 6.6 L
Engine details ...

B.F. Avery V Transmission
3-speed unsynchronized gear
Transmission details ...

B.F. Avery V Power
Engine	9 hp 6.7 kW
Plows	1 (14-inch)

Mechanical
Two-wheel drive
Manual steering
Open operator station.

Power Take-off (PTO)
Rear PTO Type	540 (1.125)

Dimensions & Tires
Wheelbase	74 inches 187 cm
Weight	1612 lbs 731 kg
Front tire	4.00-15
Rear tire	8-24
Full dimensions and tires ...

Belt Pulley
Diameter	6 inches 15 cm
Width	5.5 inches 13 cm
RPM	540
Speed	3100 ft/min 944.88 meters/min

References
Farm Equipment Catalog published in 1950, by Montgomery Ward

Engine

Engine Detail — 64.9 ci / 1.1 L Gasoline

Manufacturer	Hercules ZXB-3
Fuel Type	Gasoline
Configuration	4-cylinder, liquid-cooled
Displacement	64.9 ci 1.1 L
Bore/Stroke	2.625x3.00 inches 67 x 76 mm
Power	9 hp 6.7 kW
Air cleaner	oil bath
Rated RPM	1800
Starter	electric
Starter volts	6
Oil capacity	3 qts 2.8 L
Coolant capacity	6 qts 5.7 L

Transmission

Transmission — 3 forward and 1 reverse unsynchronized gear

Type	unsynchronized gear
Gears	3 forward and 1 reverse

Dimensions

B.F. Avery V Tires
Ag front	4.00-15
Ag rear	8-24
Ag rear	9-24

Dimensions
Wheelbase	74 inches 187 cm
Length	105 inches 266 cm
Width	51 inches 129 cm
Height	61.25 inches 155 cm
Weight	1612 lbs 731 kg
Ground clearance	23 inches 58 cm
Front tread	40 inches 101 cm
Rear tread	40 inches 101 cm

Photos

B.F. Avery V

B.F. Avery V operator station and controls.
