bolens lawn tractors 1476
 | 1970 - 1971
Large Frame SeriesGarden tractor | 1970 - 1971 | Large Frame Series | Garden tractor |
|---|---|---|---|---|
1970 - 1971 | ||||
Large Frame Series | ||||
Garden tractor | ||||
1970 - 1971 | |
|---|---|
Large Frame Series | |
Garden tractor |
Engine Detail | |
|---|---|
Wisconsin S14D | |
gasoline | |
1-cylinder | |
air-cooled horizontal-shaft horizontally-opposed | |
Displacement | 542 cc
33.1 ci |
Bore/Stroke | 3.75x3.00 inches
95 x 76 mm |
Power (gross) | 14 hp
10.4 kW |
Air cleaner | dry |
Starter | electric |
Starter volts | 12 |
Sparkplug | Champion D-16J |
Sparkplug gap | 0.030 inches
0.762 mm |
Engine Oil | |
|---|---|
 | |
Oil capacity | 2 qts
1.9 L |
