Branson 5520C

The Branson 5520C is a tractor produced by Branson. It is equipped with a 139.5 ci 2.3 L engine. The listed engine power is Diesel (listed): 55 hp / 41.0 kW. Transmission: 16 forward and reverse. Operating weight: 4349 lbs 1972 kg.

Overview

	2021 - Compact Utility tractor
2021 -
Compact Utility tractor

Production
Manufacturer	Branson (a part of TYM)
Compact Utility tractor

Variants
5520R	ROPS shuttle
5520H	ROPS hydrostatic
5520C	Cab shuttle
5520CH	Cab hydrostatic

Branson 5520C Engine
Kukje 2.3L 4-cyl diesel
Fuel tank	11.8 gal 44.7 L
Engine details ...

Branson 5520C Transmission
16-speed synchronized shuttle
Transmission details ...

Branson 5520C Power
Engine	55 hp 41.0 kW
PTO (claimed)	44 hp 32.8 kW

Mechanical
Four-wheel drive
Power steering
Cab standard.

Hydraulics
Pump flow	15.3 gpm 57.9 lpm
Steering flow	5 gpm 18.9 lpm

Power Take-off (PTO)
Rear PTO	independent
Rear PTO Type	540 (1.375)
Engine RPM	584@2600

Dimensions & Tires
Wheelbase	71.1 inches 180 cm
Weight	4349 lbs 1972 kg
Front tire	9.5-16
Rear tire	14.9-24
Full dimensions and tires ...

References
20 Series Cabs published in 2021, by Branson

Engine

Engine Detail — 139.5 ci / 2.3 L Diesel

Manufacturer	Kukje
Configuration	turbocharged diesel, 4-cylinder, liquid-cooled
Displacement	139.5 ci 2.3 L
Bore/Stroke	3.465x3.701 inches 88 x 94 mm
Emissions	Tier IV
Power	55 hp 41.0 kW
Air cleaner	dual dry
Rated RPM	2600

Transmission

Transmission — 16 forward and reverse synchronized shuttle

Type	synchronized shuttle
Gears	16 forward and reverse

Dimensions

Branson 5520C Tires
Standard tires (ag)	Front: 9.5-16. Rear: 14.9-24
Lawn/turf front	29x12.5-15
Lawn/turf rear	44x18.00-20
Industrial front	10-16.5
Industrial rear	16.9-24

Dimensions
Wheelbase	71.1 inches 180 cm
Length	127.4 inches 323 cm
Height (cab)	97.9 inches 248 cm
Weight	4349 lbs 1972 kg
Ground clearance	15.5 inches 39 cm

Attachments

Attachment overview
Front-end loader
Backhoe

Branson BH250 Backhoe
Backhoe type	Branson BH250 Backhoe
Transport height	91.2 inches 231 cm
2-Foot flat digging depth	103.2 inches 262 cm
Reach from pivot	134.4 inches 341 cm
Loading height	92.4 inches 234 cm
Bucket Rotation	151°
Swing Arc	180°
