Craftsman 131.9640
The Craftsman 131.9640 is a tractor produced by Craftsman Lawn Tractors. It is equipped with a 245 cc 15 ci engine. The listed engine power is Gasoline (listed): 7 hp / 5.2 kW. Transmission: 3 forward and 1 reverse. Operating weight: 265 lbs 120 kg.
Engine Power
Gasoline (listed): 7 hp / 5.2 kW
Fuel & Capacities
Gasoline
Transmission
3 forward and 1 reverse
Operating Weight
265 lbs
120 kg
Overview
 | 1968
Lawn tractorRoper built
Lawn tractor
Roper built |
|---|
Production | |
|---|---|
Distributor | Craftsman (a part of Sears) |
Manufacturer | Roper |
Lawn tractor | |
Original price was $385 in 1968 | |
Craftsman 131.9640 Engine | |
|---|---|
7HP Tecumseh 245cc 1-cyl gasoline | |
Engine details ...  |
Craftsman 131.9640 Transmission | |
|---|---|
3-speed gear | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Open operator station. |
Power Take-off (PTO) | |
|---|---|
Mid PTO | independent |
Dimensions & Tires | |
|---|---|
Weight | 265 lbs
120 kg |
Front tire | 11.00x4.00 |
Rear tire | 14.00x5.50 |
Full dimensions and tires ...  | |
References | |
|---|---|
 | |
Fall - Winter Catalog published in 1968, by Sears |
Engine
Engine Detail — 245 cc / 15 ci Gasoline
Manufacturer | Tecumseh |
Fuel Type | Gasoline |
Configuration | 1-cylinder, air-cooled |
Displacement | 245 cc
15 ci |
Bore/Stroke | 2.75x2.531 inches
70 x 64 mm |
Power | 7 hp
5.2 kW |
Starter type | manual recoil |
Transmission
Transmission — 3 forward and 1 reverse belt-driven gear
Type | belt-driven gear |
Gears | 3 forward and 1 reverse |
 | |
Dimensions
Craftsman 131.9640 Tires | |
|---|---|
Lawn/turf front | 11.00x4.00 |
Lawn/turf rear | 14.00x5.50 |
Dimensions | |
|---|---|
Length | 54.25 inches
137 cm |
Shipping weight | 265 lbs
120 kg |
Attachments
32" Mower deck | |
|---|---|
Type | mid-mount Craftsman |
2-blade with manual lift | |
Cutting width | 32 inches
81 cm |
Cut height | 1.75 to 3.25 inch
4 to 8 cm |
Cut positions | 5 |
Photos
Craftsman 131.9640 tractor photo
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Craftsman Lawn Tractors Craftsman 131.9640.
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Craftsman Lawn Tractors Craftsman 131.9640 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Craftsman Lawn Tractors Craftsman 131.9640.
Converted Equivalents:
Horsepower (HP)7 hp
Kilowatts (kW)5.2 kW
Metric Horsepower (PS / CV)7.1 PS
