Craftsman 502.25566 XD-11
The Craftsman 502.25566 XD-11 is a tractor produced by Craftsman Lawn Tractors. The rated power output is 11 hp 8.2 kW. Transmission: 8 forward and 1 reverse. Operating weight: 325 lbs 147 kg.
Engine Power
11 hp
8.2 kW
Fuel & Capacities
0.75 gal
2.8 L
Transmission
8 forward and 1 reverse
Operating Weight
325 lbs
147 kg
Craftsman Lawn Tractors Craftsman 502.25566 XD-11 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1986
Riding lawn mowerMurray built |
|---|---|
1986 | |
Riding lawn mower | |
Murray built | |
1986 | |
|---|---|
Riding lawn mower | |
Murray built |
Production | |
|---|---|
Distributor | Craftsman (a part of Sears) |
Manufacturer | Murray |
Riding lawn mower | |
Craftsman 502.25566 Engine | |
|---|---|
11HP 1-cyl gasoline | |
Fuel tank | 0.75 gal
2.8 L |
Engine details ...  | |
Craftsman 502.25566 Transmission | |
|---|---|
8-speed friction disc | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Open operator station. |
Dimensions & Tires | |
|---|---|
Weight | 325 lbs
147 kg |
Front tire | 11x4.0 |
Rear tire | 16x6.5 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
Craftsman Tractors and Rear Engine Riders published in 1985, by Sears | |
Spring/Summer Catalog published in 1986, by Sears |
Engine
| 1986
Riding lawn mowerMurray built |
|---|---|
1986 | |
Riding lawn mower | |
Murray built | |
1986 | |
|---|---|
Riding lawn mower | |
Murray built |
Engine Detail — Gasoline
Fuel Type | Gasoline |
Configuration | 1-cylinder, air-cooled vertical-shaft |
Power (gross) | 11 hp
8.2 kW |
Starter | electric |
Starter volts | 12 |
Transmission
| 1986
Riding lawn mowerMurray built |
|---|---|
1986 | |
Riding lawn mower | |
Murray built | |
1986 | |
|---|---|
Riding lawn mower | |
Murray built |
Transmission — 8 forward and 1 reverse friction disc
Type | friction disc |
Gears | 8 forward and 1 reverse |
Craftsman 502.25566 Transmission | |
|---|---|
 |
Dimensions
| 1986
Riding lawn mowerMurray built |
|---|---|
1986 | |
Riding lawn mower | |
Murray built | |
1986 | |
|---|---|
Riding lawn mower | |
Murray built |
Craftsman 502.25566 Tires | |
|---|---|
Lawn/turf front | 11x4.0 |
Lawn/turf rear | 16x6.5 |
Dimensions | |
|---|---|
Length | 57 inches
144 cm |
Weight | 325 lbs
147 kg |
Attachments
| 1986
Riding lawn mowerMurray built |
|---|---|
1986 | |
Riding lawn mower | |
Murray built | |
1986 | |
|---|---|
Riding lawn mower | |
Murray built |
36" Mower deck | |
|---|---|
Type | mid-mount Craftsman |
2-blade with manual lift | |
Cutting width | 36 inches
91 cm |
Overall width | 50 inches
127 cm |
Cut height | 1.5 to 4 inch
3 to 10 cm |
Cut positions | 8 |
Photos
Craftsman 502.25566 XD-11 tractor photo
Craftsman Lawn Tractors Craftsman 502.25566 XD-11 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Craftsman Lawn Tractors Craftsman 502.25566 XD-11.
Converted Equivalents:
Horsepower (HP)11 hp
Kilowatts (kW)8.2 kW
Metric Horsepower (PS / CV)11.2 PS
