Craftsman 502.8130
The Craftsman 502.8130 is a tractor produced by Craftsman Lawn Tractors. It is equipped with a 305 cc 18.65 ci engine. The rated power output is 8 hp 6.0 kW. Transmission: 3 forward and 1 reverse. Operating weight: 315 lbs 142 kg.
Engine Power
8 hp
6.0 kW
Fuel & Capacities
Gasoline
Transmission
3 forward and 1 reverse
Operating Weight
315 lbs
142 kg
Craftsman Lawn Tractors Craftsman 502.8130 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1972
Riding lawn mowerMurray built |
|---|---|
1972 | |
Riding lawn mower | |
Murray built | |
1972 | |
|---|---|
Riding lawn mower | |
Murray built |
Production | |
|---|---|
Distributor | Craftsman (a part of Sears) |
Manufacturer | Murray |
Riding lawn mower | |
Original price was $499 in 1972 | |
Craftsman 502.8130 Engine | |
|---|---|
8HP 305cc 1-cyl gasoline | |
Engine details ...  |
Craftsman 502.8130 Transmission | |
|---|---|
3-speed gear | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Open operator station. |
Power Take-off (PTO) | |
|---|---|
Mid PTO | independent |
Dimensions & Tires | |
|---|---|
Weight | 315 lbs
142 kg |
Front tire | 10.50x3.50 |
Rear tire | 13x5 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
Suburban, Farm and Ranch Catalog published in 1972, by Sears | |
Spring through Summer Catalog published in 1972, by Sears |
Engine
| 1972
Riding lawn mowerMurray built |
|---|---|
1972 | |
Riding lawn mower | |
Murray built | |
1972 | |
|---|---|
Riding lawn mower | |
Murray built |
Engine Detail — 305 cc / 18.65 ci Gasoline
Fuel Type | Gasoline |
Configuration | 1-cylinder, air-cooled vertical-shaft |
Displacement | 305 cc
18.65 ci |
Power | 8 hp
6.0 kW |
Starter | electric |
Starter volts | 12 |
Transmission
| 1972
Riding lawn mowerMurray built |
|---|---|
1972 | |
Riding lawn mower | |
Murray built | |
1972 | |
|---|---|
Riding lawn mower | |
Murray built |
Transmission — 3 forward and 1 reverse belt-driven gear
Type | belt-driven gear |
Gears | 3 forward and 1 reverse |
Dimensions
| 1972
Riding lawn mowerMurray built |
|---|---|
1972 | |
Riding lawn mower | |
Murray built | |
1972 | |
|---|---|
Riding lawn mower | |
Murray built |
Craftsman 502.8130 Tires | |
|---|---|
Lawn/turf front | 10.50x3.50 |
Lawn/turf rear | 13x5 |
Dimensions | |
|---|---|
Length | 57 inches
144 cm |
Height (steering wheel) | 39.5 inches
100 cm |
Shipping weight | 315 lbs
142 kg |
Attachments
| 1972
Riding lawn mowerMurray built |
|---|---|
1972 | |
Riding lawn mower | |
Murray built | |
1972 | |
|---|---|
Riding lawn mower | |
Murray built |
30" Mower deck | |
|---|---|
Type | mid-mount Craftsman |
2-blade with manual lift | |
Cutting width | 30 inches
76 cm |
Overall width | 43 inches
109 cm |
Cut height | 1.625 to 3.25 inch
4 to 8 cm |
Cut positions | 7 |
Photos
Craftsman 502.8130 tractor photo
Craftsman Lawn Tractors Craftsman 502.8130 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Craftsman Lawn Tractors Craftsman 502.8130.
Converted Equivalents:
Horsepower (HP)8 hp
Kilowatts (kW)6 kW
Metric Horsepower (PS / CV)8.1 PS
