Craftsman 917.25472 YT 18

The Craftsman 917.25472 YT 18 is a tractor produced by Craftsman Lawn Tractors. It is equipped with a 693 cc 42.33 ci engine. The listed engine power is Gasoline (gross): 18 hp / 13.4 kW. Transmission: Foote 4360-13. Operating weight: 515 lbs 233 kg.

Engine Power

Gasoline (gross): 18 hp / 13.4 kW

Fuel & Capacities

3.5 gal 13.2 L

Transmission

Foote 4360-13

Operating Weight

515 lbs 233 kg

Overview

	1989 Garden tractorRoper built Garden tractor Roper built

Production
Distributor	Craftsman (a part of Sears)
Manufacturer	Roper
Garden tractor

Craftsman 917.25472 Engine
18HP Briggs & Stratton 693cc 2-cyl gasoline
Fuel tank	3.5 gal 13.2 L
Engine details ...

Craftsman 917.25472 Transmission
5-speed gear
Transmission details ...

Mechanical
Two-wheel drive
Manual steering
Mechanical disc brakes
Open operator station.

Power Take-off (PTO)
Mid PTO	independent
Clutch	manual
Mid PTO Type	pulley

Dimensions & Tires
Weight	515 lbs 233 kg
Front tire	15x6.0
Rear tire	20x10.0
Full dimensions and tires ...

Electrical
Ground	negative
Battery volts	12

References

Craftsman Lawn and Garden Riding Equipment and Attachments published in 1989, by Sears

Engine

Engine Detail — 693 cc / 42.33 ci Gasoline

Manufacturer	Briggs & Stratton 422707
Fuel Type	Gasoline
Configuration	2-cylinder, air-cooled vertical-shaft opposed-twin
Displacement	693 cc 42.33 ci
Bore/Stroke	3.44x2.33 inches 87 x 59 mm
Power (gross)	18 hp 13.4 kW
Starter	electric
Starter volts	12

Craftsman 917.25472 Engine

Transmission

Transmission — Foote 4360-13

Transmission	Foote 4360-13
Type	belt-driven gear
Gears	5 forward and 1 reverse

Dimensions

Craftsman 917.25472 Tires
Lawn/turf front	15x6.0
Lawn/turf rear	20x10.0

Dimensions
Length	64 inches 162 cm
Weight	515 lbs 233 kg

Attachments

Attachment overview
44" mid-mount mower deck
Snowblower
Blade
The 25472 was compatible with the model 917.24246 21-inch belt-drive tiller.

44" Mower deck
Type	mid-mount Craftsman
	manual lift
Cutting width	44 inches 111 cm
Overall width	54 inches 137 cm
Cut height	1.5 to 4.0 inch 3 to 10 cm

Photos

Craftsman 917.25472 YT 18 tractor photo

Recommended Implements & Sizing Guide

Engineering recommendations for Craftsman Lawn Tractors Craftsman 917.25472 YT 18 based on its 18 HP power envelope and ASAE agricultural standards.

Implement & Operation	Recommended Size	Workload Rating	Engineering Notes
Moldboard PlowPrimary Tillage	1 to 2 Bottom (12")1 - 2 铧 (30 cm)	Light Duty	Ideal for garden plots and light sandy soil.
Rotary Cutter / MowerMowing & Clearing	4 ft (48 in)1.2 m	Light Duty	Pasture clipping and light brush under 1" diameter.
Rotary TillerSeedbed Prep	42 to 48 in105 - 120 cm	Light Duty	Covers compact tractor tire width.

Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for Craftsman Lawn Tractors Craftsman 917.25472 YT 18.

Estimated Continuous Field Runtime: 3.7 hrs

Approximately 3.7 hours of continuous field operation at ~75% rated power on a full tank (3.5 gal / 13.2 L).

Estimated 75% Load Fuel Burn~0.9 gal/hr (3.5 L/hr)

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)

Standard Spec: API CK-4 / CJ-4 Heavy Duty

Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)

Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)

Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix

Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze

Service Interval: 2 Years / 1500 Hours

Craftsman Lawn Tractors Craftsman 917.25472 YT 18 Specification Unit Converter

Convert power, fluid capacities, and operating weights between metric and imperial standards for Craftsman Lawn Tractors Craftsman 917.25472 YT 18.

Enter value:

Unit:

Converted Equivalents:

Horsepower (HP)18 hp

Kilowatts (kW)13.4 kW

Metric Horsepower (PS / CV)18.2 PS
