Craftsman 917.25772

The Craftsman 917.25772 is a tractor produced by Craftsman Lawn Tractors. It is equipped with a 691 cc 42.18 ci engine. The listed engine power is Gasoline (gross): 18 hp / 13.4 kW. Transmission: 6 forward and 2 reverse.

Engine Power

Gasoline (gross): 18 hp / 13.4 kW

Fuel & Capacities

3.5 gal 13.2 L

Transmission

6 forward and 2 reverse

Overview

	1994 GT6000 SeriesGarden tractorAYP built GT6000 Series Garden tractor AYP built

Production
Distributor	Craftsman (a part of Sears)
Manufacturer	AYP
Garden tractor

Variants
25772	gear
25773	hydrostatic

Craftsman 917.25772 Engine
18HP Kohler 691cc 2-cyl gasoline
Fuel tank	3.5 gal 13.2 L
Engine details ...

Craftsman 917.25772 Transmission
6-speed gear
Transmission details ...

Mechanical
Two-wheel drive
Manual steering
Open operator station.

Tractor hitch
Type	sleeve hitch OptOptional

Power Take-off (PTO)
Mid PTO	independent
Clutch	electric

Dimensions & Tires
Front tire	16x6.5-8
Rear tire	23x10.5-12
Full dimensions and tires ...

Electrical
Ground	negative
Charging amps	15
Battery volts	12

References

Craftsman Lawn and Garden Rding Equipment published in 1994, by Sears

Engine

Engine Detail — 691 cc / 42.18 ci Gasoline

Manufacturer	Kohler MV18S
Fuel Type	Gasoline
Configuration	2-cylinder, air-cooled vertical-shaft opposed-twin
Displacement	691 cc 42.18 ci
Bore/Stroke	3.12x2.75 inches 79 x 70 mm
Power (gross)	18 hp 13.4 kW
Starter	electric
Starter volts	12
Sparkplug	Champion RV17YC
Sparkplug gap	0.025 inches 0.635 mm
Oil capacity	2 qts 1.9 L
Oil change	25 h

Craftsman 917.25772 Engine

Transmission

Transmission — 6 forward and 2 reverse belt-driven gear

Type	belt-driven gear
Gears	6 forward and 2 reverse
Oil capacity	4 qts 3.8 L
Oil type	SAE 30

Dimensions

Craftsman 917.25772 Tires
Lawn/turf front	16x6.5-8
Lawn/turf rear	23x10.5-12

Dimensions

Attachments

Attachment overview
44" mid-mount mower deck
Snowblower
Blade
Garden tractors are capable of using tillers, plows, or other ground-engaging attachments. TractorData does not list details of these attachments.

44" Mower deck
Type	mid-mount Craftsman
	3-blade with manual lift
Cutting width	44 inches 111 cm
Cut height	1.5 to 4.5 inch 3 to 11 cm

Photos

Craftsman 917.25772 tractor photo

Recommended Implements & Sizing Guide

Engineering recommendations for Craftsman Lawn Tractors Craftsman 917.25772 based on its 18 HP power envelope and ASAE agricultural standards.

Implement & Operation	Recommended Size	Workload Rating	Engineering Notes
Moldboard PlowPrimary Tillage	1 to 2 Bottom (12")1 - 2 铧 (30 cm)	Light Duty	Ideal for garden plots and light sandy soil.
Rotary Cutter / MowerMowing & Clearing	4 ft (48 in)1.2 m	Light Duty	Pasture clipping and light brush under 1" diameter.
Rotary TillerSeedbed Prep	42 to 48 in105 - 120 cm	Light Duty	Covers compact tractor tire width.

Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for Craftsman Lawn Tractors Craftsman 917.25772.

Estimated Continuous Field Runtime: 3.7 hrs

Approximately 3.7 hours of continuous field operation at ~75% rated power on a full tank (3.5 gal / 13.2 L).

Estimated 75% Load Fuel Burn~0.9 gal/hr (3.5 L/hr)

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)

Standard Spec: API CK-4 / CJ-4 Heavy Duty

Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)

Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)

Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix

Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze

Service Interval: 2 Years / 1500 Hours

Craftsman Lawn Tractors Craftsman 917.25772 Specification Unit Converter

Convert power, fluid capacities, and operating weights between metric and imperial standards for Craftsman Lawn Tractors Craftsman 917.25772.

Enter value:

Unit:

Converted Equivalents:

Horsepower (HP)18 hp

Kilowatts (kW)13.4 kW

Metric Horsepower (PS / CV)18.2 PS
