craftsman lawn tractors 917 27223
 | 2001
Lawn tractorAYP built | 2001 | Lawn tractor | AYP built |
|---|---|---|---|---|
2001 | ||||
Lawn tractor | ||||
AYP built | ||||
2001 | |
|---|---|
Lawn tractor | |
AYP built |
Engine Detail | |
|---|---|
Kohler CV624 | |
gasoline | |
2-cylinder | |
air-cooled vertical-shaft V-Twin | |
Displacement | 624 cc
38.1 ci |
Bore/Stroke | 3.03x2.64 inches
77 x 67 mm |
Power (gross) | 20 hp
14.9 kW |
Rated RPM | 3600 |
Starter | electric |
Starter volts | 12 |
Sparkplug | Champion RC12YC |
Sparkplug gap | 0.030 inches
0.762 mm |
Engine Oil | |
|---|---|
 | |
Oil capacity | 2.25 qts
2.1 L |
Oil change | 25 h |
