Craftsman 917.27324

The Craftsman 917.27324 is a tractor produced by Craftsman Lawn Tractors. It is equipped with a 724 cc 44.2 ci engine. The listed engine power is Gasoline (gross): 25 hp / 18.6 kW. Transmission: Hydro-Gear 336-0510.

Engine Power

Gasoline (gross): 25 hp / 18.6 kW

Fuel & Capacities

4 gal 15.1 L

Transmission

Hydro-Gear 336-0510

Overview

	2003 DYT 4000 SeriesLawn tractorAYP built DYT 4000 Series Lawn tractor AYP built

Production
Distributor	Craftsman (a part of Sears)
Manufacturer	AYP
Lawn tractor

Craftsman 917.27324 Engine
25HP Kohler 724cc 2-cyl gasoline
Fuel tank	4 gal 15.1 L
Engine details ...

Craftsman 917.27324 Transmission
hydrostatic
Transmission details ...

Mechanical
Two-wheel drive
Manual steering
Open operator station.

Power Take-off (PTO)
Mid PTO	independent
Clutch	electric

Dimensions & Tires
Front tire	15x6.0-6
Rear tire	20x10-8
Full dimensions and tires ...

Electrical
Ground	negative
Battery volts	12

References

2003 Riding Equipment and Attachments published by Sears

Engine

Engine Detail — 724 cc / 44.2 ci Gasoline

Manufacturer	Kohler CV730
Fuel Type	Gasoline
Configuration	2-cylinder, air-cooled vertical-shaft V-Twin
Displacement	724 cc 44.2 ci
Bore/Stroke	3.3x2.6 inches 84 x 66 mm
Power (gross)	25 hp 18.6 kW
Starter	electric
Starter volts	12
Sparkplug	Champion RC12YC
Sparkplug gap	0.030 inches 0.762 mm
Oil capacity	2 qts 1.9 L

Transmission

Transmission — Hydro-Gear 336-0510

Transmission	Hydro-Gear 336-0510
Type	belt-driven hydrostatic
Gears	infinite forward and reverse
Oil change	sealed unit, owner service is not recommended

Dimensions

Craftsman 917.27324 Tires
Lawn/turf front	15x6.0-6
Lawn/turf rear	20x10-8

Dimensions

Attachments

48" Mower deck
Type	mid-mount Craftsman
	3-blade with manual lift
Cutting width	48 inches 121 cm

Photos

Craftsman 917.27324 tractor photo

Recommended Implements & Sizing Guide

Engineering recommendations for Craftsman Lawn Tractors Craftsman 917.27324 based on its 25 HP power envelope and ASAE agricultural standards.

Implement & Operation	Recommended Size	Workload Rating	Engineering Notes
Moldboard PlowPrimary Tillage	1 to 2 Bottom (12")1 - 2 铧 (30 cm)	Light Duty	Ideal for garden plots and light sandy soil.
Rotary Cutter / MowerMowing & Clearing	5 ft (60 in)1.5 m	Medium Duty	Pasture maintenance and weeds up to 1.5" diameter.
Rotary TillerSeedbed Prep	54 to 60 in135 - 150 cm	Medium Duty	Thorough seedbed preparation in orchards and vegetable plots.
Disc HarrowSecondary Tillage	5 to 6 ft (16-18" discs)1.5 - 1.8 m (40-45 cm 耙片)	Light Duty	Small acreage soil break-up and secondary aeration.

Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for Craftsman Lawn Tractors Craftsman 917.27324.

Estimated Continuous Field Runtime: 3.1 hrs

Approximately 3.1 hours of continuous field operation at ~75% rated power on a full tank (4 gal / 15.1 L).

Estimated 75% Load Fuel Burn~1.3 gal/hr (4.9 L/hr)

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)

Standard Spec: API CK-4 / CJ-4 Heavy Duty

Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)

Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)

Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix

Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze

Service Interval: 2 Years / 1500 Hours

Craftsman Lawn Tractors Craftsman 917.27324 Specification Unit Converter

Convert power, fluid capacities, and operating weights between metric and imperial standards for Craftsman Lawn Tractors Craftsman 917.27324.

Enter value:

Unit:

Converted Equivalents:

Horsepower (HP)25 hp

Kilowatts (kW)18.6 kW

Metric Horsepower (PS / CV)25.3 PS
