Craftsman Professional 247.28980
The Craftsman Professional 247.28980 is a tractor produced by Craftsman Professional Lawn Tractors. It is equipped with a 724 cc 44.18 ci engine. The listed engine power is Gasoline (gross): 24 hp / 17.9 kW. Transmission: infinite forward and reverse. Operating weight: 594 lbs 269 kg.
Engine Power
Gasoline (gross): 24 hp / 17.9 kW
Fuel & Capacities
Gasoline
Transmission
infinite forward and reverse
Operating Weight
594 lbs
269 kg
Overview
 | 2010 -
PYT 9000 SeriesLawn tractorMTD built |
|---|---|
2010 - | |
PYT 9000 Series | |
Lawn tractor | |
MTD built | |
2010 - | |
|---|---|
PYT 9000 Series | |
Lawn tractor | |
MTD built |
Production | |
|---|---|
Distributor | Craftsman Professional (a part of Sears) |
Manufacturer | MTD |
Lawn tractor | |
Original price | $2,485 (2010) |
Craftsman Professional 247.28980 Engine | |
|---|---|
24HP Briggs & Stratton 724cc 2-cyl gasoline | |
Engine details ...  |
Craftsman Professional 247.28980 Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Steering | manual sector and pinion |
Disc brakes | |
Dimensions & Tires | |
|---|---|
Weight | 594 lbs
269 kg |
Front tire | 15x6 |
Rear tire | 20x8 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
2011 Customer Buying Guide published by Sears |
Engine
| 2010 -
PYT 9000 SeriesLawn tractorMTD built |
|---|---|
2010 - | |
PYT 9000 Series | |
Lawn tractor | |
MTD built | |
2010 - | |
|---|---|
PYT 9000 Series | |
Lawn tractor | |
MTD built |
Engine Detail — 724 cc / 44.18 ci Gasoline
Manufacturer | Briggs & Stratton |
Fuel Type | Gasoline |
Configuration | 2-cylinder, air-cooled |
Displacement | 724 cc
44.18 ci |
Power (gross) | 24 hp
17.9 kW |
Air cleaner | cartridge |
Starter | electric |
Starter volts | 12 |
Sparkplug | Champion RC12YC |
Sparkplug gap | 0.030 inches
0.762 mm |
Transmission
| 2010 -
PYT 9000 SeriesLawn tractorMTD built |
|---|---|
2010 - | |
PYT 9000 Series | |
Lawn tractor | |
MTD built | |
2010 - | |
|---|---|
PYT 9000 Series | |
Lawn tractor | |
MTD built |
Transmission — infinite forward and reverse hydrostatic
Type | hydrostatic |
Gears | infinite forward and reverse |
Towing release on rear of tractor. Pull lever out and up to free-wheel. | |
Dimensions
| 2010 -
PYT 9000 SeriesLawn tractorMTD built |
|---|---|
2010 - | |
PYT 9000 Series | |
Lawn tractor | |
MTD built | |
2010 - | |
|---|---|
PYT 9000 Series | |
Lawn tractor | |
MTD built |
Craftsman Professional 247.28980 Tires | |
|---|---|
Lawn/turf front | 15x6 |
Lawn/turf rear | 20x8 |
Dimensions | |
|---|---|
Weight | 594 lbs
269 kg |
Attachments
| 2010 -
PYT 9000 SeriesLawn tractorMTD built |
|---|---|
2010 - | |
PYT 9000 Series | |
Lawn tractor | |
MTD built | |
2010 - | |
|---|---|
PYT 9000 Series | |
Lawn tractor | |
MTD built |
42" Mower deck | |
|---|---|
Type | mid-mount Craftsman |
2-blade with manual lift | |
Cutting width | 42 inches
106 cm |
Cut height | 1.5 to 4 inch
3 to 10 cm |
Cut positions | 12 |
Photos
Craftsman Professional 247.28980 tractor photo
Recommended Implements & Sizing Guide
Engineering recommendations for Craftsman Professional Lawn Tractors Craftsman Professional 247.28980 based on its 24 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 1 to 2 Bottom (12")1 - 2 铧 (30 cm) | Light Duty | Ideal for garden plots and light sandy soil. |
Rotary Cutter / MowerMowing & Clearing | 4 ft (48 in)1.2 m | Light Duty | Pasture clipping and light brush under 1" diameter. |
Rotary TillerSeedbed Prep | 42 to 48 in105 - 120 cm | Light Duty | Covers compact tractor tire width. |
Disc HarrowSecondary Tillage | 5 to 6 ft (16-18" discs)1.5 - 1.8 m (40-45 cm 耙片) | Light Duty | Small acreage soil break-up and secondary aeration. |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Craftsman Professional Lawn Tractors Craftsman Professional 247.28980.
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Craftsman Professional Lawn Tractors Craftsman Professional 247.28980 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Craftsman Professional Lawn Tractors Craftsman Professional 247.28980.
Converted Equivalents:
Horsepower (HP)24 hp
Kilowatts (kW)17.9 kW
Metric Horsepower (PS / CV)24.3 PS
Direct Competitor Comparison
Compare Craftsman Professional 247.28980 against same-era industry alternatives in the same horsepower class.
Current Model
Craftsman Professional Lawn Tractors
Craftsman Professional 247.28980
Engine Power:Gasoline (gross): 24 hp / 17.9 kW
★ Baseline Reference
