Deutz-Fahr Agrotron 215
The Deutz-Fahr Agrotron 215 is a tractor produced by Deutz Fahr. It is equipped with a 436.1 ci 7.1 L engine. The rated power output is 197.1 hp 147.0 kW. Transmission: ZF 7300. Operating weight: 18541 lbs 8410 kg.
Engine Power
197.1 hp
147.0 kW
Fuel & Capacities
95.1 gal
360.0 L
Transmission
ZF 7300
Operating Weight
18541 lbs
8410 kg
Deutz Fahr Deutz-Fahr Agrotron 215 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 2004 - 2006
Agrotron SeriesRow-Crop tractor |
|---|---|
2004 - 2006 | |
Agrotron Series | |
Row-Crop tractor | |
Production | |
|---|---|
Manufacturer | Deutz-Fahr |
Row-Crop tractor | |
Deutz-Fahr Agrotron 215 Engine | |
|---|---|
Deutz 7.1L 6-cyl diesel | |
Fuel tank | 95.1 gal
360.0 L |
145.3 galOptOptional
550.0 L | |
Engine details ...  | |
Deutz-Fahr Agrotron 215 Transmission | |
|---|---|
40-speed four-speed power shift | |
Transmission details ...  |
Deutz-Fahr Agrotron 215 Power | |
|---|---|
Engine (net) | 197.1 hp
147.0 kW |
Engine (max) | 226.6 hp
169.0 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Final drives | planetary |
Differential lock | electro-hydraulic front and rear |
Power steering | |
Hydraulic wet disc brakes | |
Cab standard with air-conditioning. | |
Hydraulics | |
|---|---|
Type | closed center load sensing |
Pressure | 2901 psi
200.0 bar |
Pump flow | 31.7 gpm
120.0 lpm |
Tractor hitch | |
|---|---|
Rear Type | III |
Rear lift | 23100 lbs
10478 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Clutch | electro-hydraulic |
Rear PTO Type | 540/1000 (1.375) |
1000 (1.75) | |
Front PTO | independent |
Clutch | electro-hydraulic |
Front PTO Type | 1000 |
Dimensions & Tires | |
|---|---|
Wheelbase | 121.6 inches
308 cm |
Weight | 18541 lbs
8410 kg |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Battery volts | 12 |
References | |
|---|---|
 | |
Agrotron 215-265 published in 2005, by Deutz-Fahr |
Engine
Engine Detail — 436.1 ci / 7.1 L Diesel
Manufacturer | Deutz BF6M1013EC |
Configuration | turbocharged intercooled diesel, 6-cylinder, liquid-cooled |
Displacement | 436.1 ci
7.1 L |
Bore/Stroke | 4.25x5.12 inches
108 x 130 mm |
Rated Power (net) | 197.1 hp
147.0 kW |
Maximum Power (net) | 207.9 hp
155.0 kW |
Maximum Power (gross) | 226.6 hp
169.0 kW |
Rated RPM | 2300 |
Torque | 638 lb-ft
865.1 Nm |
Torque RPM | 1200 |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission — ZF 7300
Transmission | ZF 7300 |
Type | four-speed power shift |
Gears | 40 forward and reverse |
Four power shift speeds in six ranges with power shuttle, plus an additional four creeper ranges. | |
 | |
Dimensions
Deutz-Fahr Agrotron 215 Tires |
|---|
Dimensions | |
|---|---|
Wheelbase | 121.6 inches
308 cm |
Length | 196.9 inches
500 cm |
Height (cab) | 128.2 inches
325 cm |
Shipping weight | 18541 lbs
8410 kg |
