Deutz-Fahr Agrotron 230
The Deutz-Fahr Agrotron 230 is a tractor produced by Deutz Fahr. It is equipped with a 436.1 ci 7.1 L engine. The rated power output is 230 hp 171.5 kW. Transmission: ZF T 7300. Operating weight: 18409 lbs 8350 kg.
Engine Power
230 hp
171.5 kW
Fuel & Capacities
145.3 gal
550.0 L
Transmission
ZF T 7300
Operating Weight
18409 lbs
8350 kg
Deutz Fahr Deutz-Fahr Agrotron 230 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1998 - 2001
Agrotron SeriesRow-Crop tractor |
|---|---|
1998 - 2001 | |
Agrotron Series | |
Row-Crop tractor | |
Production | |
|---|---|
Manufacturer | Deutz-Fahr |
Row-Crop tractor | |
Deutz-Fahr Agrotron 230 Engine | |
|---|---|
SAME 7.1L 6-cyl diesel | |
Fuel tank | 145.3 gal
550.0 L |
Engine details ...  | |
Deutz-Fahr Agrotron 230 Transmission | |
|---|---|
40-speed four-speed power shift | |
Transmission details ...  |
Deutz-Fahr Agrotron 230 Power | |
|---|---|
Engine | 230 hp
171.5 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Power steering | |
Hydraulic wet disc brakes | |
Cab standard with air-conditioning. |
Hydraulics | |
|---|---|
Type | closed center |
Pump flow | 31.7 gpm
120.0 lpm |
Tractor hitch | |
|---|---|
Rear Type | III |
Rear lift | 23149 lbs
10500 kg |
Front Hitch | II OptOptional |
Front lift | 11244 lbs
5100 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Clutch | electro-hydraulic wet disc |
Rear PTO Type | 1000 (1.75) |
Front PTO | independent OptOptional |
Front PTO Type | 1000 |
Dimensions & Tires | |
|---|---|
Wheelbase | 121.6 inches
308 cm |
Weight | 18409 lbs
8350 kg |
Front tire | 520/70R38 |
Rear tire | 620/85R38 |
Full dimensions and tires ...  | |
Engine
Engine Detail — 436.1 ci / 7.1 L Diesel
Manufacturer | SAME BF6M 1013 FC |
Configuration | turbocharged diesel, 6-cylinder, liquid-cooled inline |
Displacement | 436.1 ci
7.1 L |
Bore/Stroke | 4.25x5.12 inches
108 x 130 mm |
Power | 230 hp
171.5 kW |
Rated RPM | 2350 |
Deutz-Fahr Agrotron 230 Engine | |
|---|---|
 |
Transmission
Transmission — ZF T 7300
Transmission | ZF T 7300 |
Type | four-speed power shift |
Gears | 40 forward and reverse |
Clutch | hydraulic wet disc |
Six gear, plus four in the creeper range, with four-speed power shift per gear. Power shuttle. | |
 | |
Dimensions
Deutz-Fahr Agrotron 230 Tires | |
|---|---|
Ag front | 520/70R38 |
Ag rear | 620/85R38 |
Dimensions | |
|---|---|
Wheelbase | 121.6 inches
308 cm |
Length | 171.7 inches
436 cm |
202 inches*With hitch
513 cm | |
Width | 98 inches*Minimum width.
248 cm |
Height (cab) | 127 inches
322 cm |
Shipping weight | 18409 lbs
8350 kg |
Max weight | 30865 lbs
14000 kg |
Ground clearance | 21.3 inches
54 cm |
Photos
Deutz-Fahr Agrotron 230 tractor photo
