Deutz-Fahr Agrotron 230 MK3
The Deutz-Fahr Agrotron 230 MK3 is a tractor produced by Deutz Fahr. It is equipped with a 436 ci 7.1 L engine. The rated power output is 230 hp 171.5 kW. Transmission: 40 forward and reverse. Operating weight: 19646 lbs 8911 kg.
Engine Power
230 hp
171.5 kW
Fuel & Capacities
145.3 gal
550.0 L
Transmission
40 forward and reverse
Operating Weight
19646 lbs
8911 kg
Deutz Fahr Deutz-Fahr Agrotron 230 MK3 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 2001 - 2003
Agrotron SeriesRow-Crop tractor |
|---|---|
2001 - 2003 | |
Agrotron Series | |
Row-Crop tractor | |
Production | |
|---|---|
Manufacturer | Deutz-Fahr |
Row-Crop tractor | |
Deutz-Fahr Agrotron 230 MK3 Engine | |
|---|---|
Deutz 7.1L 6-cyl diesel | |
Fuel tank | 145.3 gal
550.0 L |
Engine details ...  | |
Deutz-Fahr Agrotron 230 MK3 Transmission | |
|---|---|
40-speed 4-speed power shift | |
Transmission details ...  |
Deutz-Fahr Agrotron 230 MK3 Power | |
|---|---|
Engine | 230 hp
171.5 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Power steering | |
Wet disc brakes | |
Cab standard with air-conditioning. |
Hydraulics | |
|---|---|
Pump flow | 31.7 gpm
120.0 lpm |
Tractor hitch | |
|---|---|
Rear Type | III |
Rear lift | 23152 lbs
10501 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 1000 |
Dimensions & Tires | |
|---|---|
Wheelbase | 121.5 inches
308 cm |
Weight | 19646 lbs
8911 kg |
Front tire | 18.4R34 |
Rear tire | 20.8R42 |
Full dimensions and tires ...  | |
References | |
|---|---|
 | |
Agrotron 230 MK3 - 260 MK3 published in 2002, by Deutz-Fahr | |
Agrotron 230 260 MK3 published in 2004, by Deutz-Fahr |
Engine
Engine Detail — 436 ci / 7.1 L Diesel
Manufacturer | Deutz BF6M 1013C |
Configuration | turbocharged intercooled diesel, 6-cylinder, liquid-cooled inline |
Displacement | 436 ci
7.1 L |
Bore/Stroke | 4.252x5.12 inches
108 x 130 mm |
Power | 230 hp
171.5 kW |
Rated RPM | 2350 |
Transmission
Transmission — 40 forward and reverse 4-speed power shift
Type | 4-speed power shift |
Gears | 40 forward and reverse |
Four power shift gears in six ranges with additional four-range creeper. | |
Dimensions
Deutz-Fahr Agrotron 230 MK3 Tires | |
|---|---|
Ag front | 18.4R34 |
Ag rear | 20.8R42 |
Dimensions | |
|---|---|
Wheelbase | 121.5 inches
308 cm |
Length | 202 inches
513 cm |
Height | 129.8 inches
329 cm |
Weight | 19646 lbs
8911 kg |
