Farmall 404

The Farmall 404 is a tractor produced by Farmall. It is equipped with a 134.8 ci 2.2 L engine. The rated power output is 36.70 hp 27.4 kW. Transmission: Dual-Range. Operating weight: 3400 to 4115 pounds.

Overview

	1961 - 1968 Row-Crop tractor
1961 - 1968
Row-Crop tractor

Production
Manufacturer	Farmall (a part of International Harvester)
Row-Crop tractor
Built in Louisville, Kentucky, USA
Total built	2440

Variants
Farmall 404	row-crop chassis
IH 404	utility chassis
2404	industrial

Farmall 404 Power
Drawbar (claimed)	33.4 hp (gas) 24.9 kW
	29 hp (LP) 21.6 kW
PTO (claimed)	36.7 hp (gas) 27.4 kW
	33 hp (LP) 24.6 kW
Plows	2-3
Drawbar (tested)	32.97 hp 24.6 kW
PTO (tested)	36.70 hp 27.4 kW
Performance test details ...

Mechanical
Two-wheel drive
Steering	manual
	power (optional)
Differential mechanical disc brakes
Open operator station. Optional deluxe deep-cushion seat with padded backrest.

Capacity
Fuel	16.2 gal (gas) 61.3 L
	19 gal (LP-gas) 71.9 L
Hydraulic system	5 gal 18.9 L

Hydraulics
Type	live
Capacity	5 gal 18.9 L
Valves	1 or 2
Total flow	4.5 gpm 17.0 lpm
	9.3 gpm (optional) 35.2 lpm

Tractor hitch
Rear Type	I

Power Take-off (PTO)
Rear PTO	transmission
Rear PTO Type	540

Dimensions & Tires
Wheelbase	82.2 inches (tricycle) 208 cm
	87.8 inches (wide front) 223 cm
Weight	3400 to 4115 pounds
Front tire	5.00-15
Rear tire	11.2-36
Full dimensions and tires ...

Belt Pulley
Diameter	11 inches 27 cm
RPM	948
Speed	2,730 ft/min 832.10 meters/min

References
Farm Loaders published in 1962, by International Harvester
Farmall and International 404 Tractors published by International Harvester

Engine

Engine options
International Harvester 2.2L 4-cyl gasoline
International Harvester 2.2L 4-cyl LP-gas

Engine Detail — 134.8 ci / 2.2 L Gasoline

Manufacturer	International Harvester C-135
Fuel Type	Gasoline
Configuration	4-cylinder, liquid-cooled
Displacement	134.8 ci 2.2 L
Bore/Stroke	3.25x4.0625 inches 83 x 103 mm
Air cleaner	oil bath
Compression	7.7:1
Rated RPM	2000
Idle RPM	900-2000
Starter volts	12
Oil capacity	7 qts 6.6 L
Coolant capacity	15 qts 14.2 L

Engine Detail — 134.8 ci / 2.2 L

Manufacturer	International Harvester C-135
Configuration	4-cylinder, liquid-cooled
LP-gas
Displacement	134.8 ci 2.2 L
Bore/Stroke	3.25x4.0625 inches 83 x 103 mm
Air cleaner	oil bath
Compression	8:1
Rated RPM	2000
Starter volts	12
Oil capacity	7 qts 6.6 L
Coolant capacity	15 qts 14.2 L

Transmission

Transmission options
4-speed gear
8-speed
4-speed manual shuttle

Transmission — 4 forward and 1 reverse gear

Type	gear
Gears	4 forward and 1 reverse
Clutch	9-inch dry disc
Oil capacity	20 qts 18.9 L
With 11.2-36 rear tires.

Transmission — Dual-Range

Transmission	Dual-Range
Gears	8 forward and 2 reverse
Clutch	9-inch dry disc
Oil capacity	20 qts 18.9 L
Add high range to basic four-speed transmission.
With 11.2-36 rear tires.

Transmission — 4 forward and reverse manual shuttle

Type	manual shuttle
Gears	4 forward and reverse
Clutch	9-inch dry disc
Oil capacity	20 qts 18.9 L
With 11.2-36 rear tires.

Dimensions

Farmall 404 Tires
Ag front	5.00-15
Ag rear	11.2-36
Ag rear	12.4-36

Dimensions
Wheelbase	82.2 inches (tricycle) 208 cm
	87.8 inches (wide front) 223 cm
Length	94 inches 238 cm
Height (steering wheel)	64.1 inches 162 cm
Front tread	8 inches 20 cm (tricycle)
Front tread	50 to 82 inches 127 to 208 cm
Rear tread	48 to 80 inches 121 to 203 cm
Rear tread	48 to 88 inches 121 to 223 cm (long axle)

Farmall 404 Weight
Shipping	3,400 lbs 1542 kg
Operating	4,115 lbs 1866 kg
Ballasted	6,645 lbs 3014 kg

Tests

Nebraska Tractor Test 818
Gasoline 8-speed 2WD May 21 - June 4, 1962 Link: Nebraska Tractor Test 818 file
PTO performance
Power at rated engine speed	36.70 hp 27.4 kW
Fuel use	3.0 gal/hour 11.4 l/hour
Drawbar performance
Max power	32.97 hp 24.6 kW
Fuel use	3.0 gal/hour 11.4 l/hour
Gear 3-Low used for power test.
Max pull	4,999 lbs 2267 kg
Gear 1-Low used for pull test.

Attachments

Attachment overview
International Harvester 2001 loader
Matched equipment for the Farmall 404 included the 209A two-bottom or 309A three-bottom plows, and the model 200 rear-mounted cultivator.

Photos

Farmall 404

Farmall 404

Farmall 404

Farmall 404

Farmall 404

International Farmall 404 operator station and controls.
