Fiat 211R

The Fiat 211R is a tractor produced by Fiat. It is equipped with a 69.5 ci 1.1 L engine. The rated power output is 21.13 hp 15.8 kW. Transmission: 6 forward and 2 reverse. Operating weight: 1984 lbs 899 kg.

Overview

	1959 - 1964 200 SeriesUtility tractor
1959 - 1964
200 Series
Utility tractor

Production
Manufacturer	Fiat
Utility tractor
Built in Modena, Italy

Variants
241	4WD
Normal	utility chassis
Frutal	low-profile
Vinedo	narrow-profile

Fiat 211R Engine
FIAT 1.1L 2-cyl diesel
Engine details ...

Fiat 211R Transmission
6-speed gear
Transmission details ...

Fiat 211R Power
Engine	21.13 hp 15.8 kW
Drawbar (claimed)	18.43 hp 13.7 kW
Belt (claimed)	19.31 hp 14.4 kW

Mechanical
Two-wheel drive
Manual steering
Open operator station.

Tractor hitch
Rear Type	I

Power Take-off (PTO)
Rear PTO Type	540
Engine RPM	540@2120

Dimensions & Tires
Wheelbase	66.9 inches 169 cm
Weight	1984 lbs 899 kg
Front tire	4.00-15
Rear tire	9-24
Full dimensions and tires ...

Electrical
Ground	negative
Battery volts	12

References
1000 Super
211R published by Fiat
211r

Engine

Engine Detail — 69.5 ci / 1.1 L Diesel

Manufacturer	FIAT
Fuel Type	Diesel
Configuration	2-cylinder, liquid-cooled
Displacement	69.5 ci 1.1 L
Bore/Stroke	3.35x3.94 inches 85 x 100 mm
Power	21.13 hp 15.8 kW
Compression	21.5:1
Rated RPM	2300
Starter volts	12

Transmission

Transmission — 6 forward and 2 reverse gear

Type	gear
Gears	6 forward and 2 reverse

Dimensions

Fiat 211R Tires
Ag front	4.00-15
Ag rear	9-24

Dimensions
Wheelbase	66.9 inches 169 cm
Length	102.4 inches 260 cm
Width	47.375 inches 120 cm
	75.25 inches 191 cm
Height (steering wheel)	61.4 inches 155 cm
Height (hood)	51.4 inches 130 cm
Weight	1984 lbs 899 kg
Ground clearance	19.7 inches 50 cm
Front tread	41.3 to 65 inches 104 to 165 cm
Rear tread	39.4 to 66.9 inches 100 to 169 cm

Photos

Fiat 211R
