Huffy Caprice II 1110
The Huffy Caprice II 1110 is a tractor produced by Huffy Lawn Tractors. The listed engine power is Gasoline (gross): 10 hp / 7.5 kW. Transmission: 3 forward and 1 reverse. Operating weight: 369 lbs 167 kg.
Engine Power
Gasoline (gross): 10 hp / 7.5 kW
Fuel & Capacities
Gasoline
Transmission
3 forward and 1 reverse
Operating Weight
369 lbs
167 kg
Overview
 | 1971
Lawn tractor |
|---|
Production | |
|---|---|
Manufacturer | Huffy |
Lawn tractor | |
Huffy Caprice II 1110 Engine | |
|---|---|
10HP Tecumseh 1-cyl gasoline | |
Engine details ...  |
Huffy Caprice II 1110 Transmission | |
|---|---|
3-speed gear | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Open operator station. |
Power Take-off (PTO) | |
|---|---|
Mid PTO | independent |
Clutch | manual |
Dimensions & Tires | |
|---|---|
Weight | 369 lbs
167 kg |
Front tire | 13x5.00 |
Rear tire | 16x7.50 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Battery volts | 12 |
References | |
|---|---|
 | |
Huffy Leisure Makers published in 1971, by Huffman Manufacturing |
Engine
Engine Detail — Gasoline
Manufacturer | Tecumseh |
Fuel Type | Gasoline |
Configuration | 1-cylinder, air-cooled vertical-shaft |
Power (gross) | 10 hp
7.5 kW |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission — 3 forward and 1 reverse belt-driven gear
Type | belt-driven gear |
Gears | 3 forward and 1 reverse |
Dimensions
Huffy Caprice II 1110 Tires | |
|---|---|
Lawn/turf front | 13x5.00 |
Lawn/turf rear | 16x7.50 |
Dimensions | |
|---|---|
Weight | 369 lbs
167 kg |
Attachments
Attachment overview | |
|---|---|
32" mid-mount mower deck | |
Blade |
32" Mower deck | |
|---|---|
Type | mid-mount Huffy |
2-blade with manual lift | |
Cutting width | 32 inches
81 cm |
Cut height | 1.75 to 3.5 inch
4 to 8 cm |
Photos
Huffy Caprice II 1110 tractor photo
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Huffy Lawn Tractors Huffy Caprice II 1110.
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Huffy Lawn Tractors Huffy Caprice II 1110 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Huffy Lawn Tractors Huffy Caprice II 1110.
Converted Equivalents:
Horsepower (HP)10 hp
Kilowatts (kW)7.5 kW
Metric Horsepower (PS / CV)10.1 PS
