Huffy Fairlane 1010

The Huffy Fairlane 1010 is a tractor produced by Huffy Lawn Tractors. The listed engine power is Gasoline (gross): 5 hp / 3.7 kW. Transmission: 1 forward and reverse. Operating weight: 120 lbs 54 kg.

Engine Power
Gasoline (gross): 5 hp / 3.7 kW
Fuel & Capacities
Gasoline
Transmission
1 forward and reverse
Operating Weight
120 lbs 54 kg

Overview

Huffy Fairlane 1010 tractor photo
1971 Lawn tractor
Production
Manufacturer
Huffy
Lawn tractor
Huffy Fairlane 1010 Engine
5HP Briggs & Stratton 1-cyl gasoline
Engine details ...
Huffy Fairlane 1010 Transmission
1-speed gear
Transmission details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station.
Power Take-off (PTO)
Mid PTO
independent
Clutch
manual
Dimensions & Tires
Weight
120 lbs 54 kg
Front tire
8
Rear tire
10
Full dimensions and tires ...
References
Fairlane 1010 references literature
Huffy Leisure Makers published in 1971, by Huffman Manufacturing

Engine

Engine Detail — Gasoline

Manufacturer
Briggs & Stratton
Fuel Type
Gasoline
Configuration
1-cylinder, air-cooled vertical-shaft
Power (gross)
5 hp 3.7 kW
Starter type
manual recoil

Transmission

Transmission — 1 forward and reverse belt-driven gear

Type
belt-driven gear
Gears
1 forward and reverse

Dimensions

Huffy Fairlane 1010 Tires
Lawn/turf front
8
Lawn/turf rear
10
Dimensions
Weight
120 lbs 54 kg

Attachments

24" Mower deck
Type
mid-mount Huffy
1-blade with manual lift
Cutting width
24 inches 60 cm
Cut height
2 to 2.75 inch 5 to 6 cm

Photos

Huffy Fairlane 1010 tractor photo

Huffy Fairlane 1010 tractor photo

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for Huffy Lawn Tractors Huffy Fairlane 1010.

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours

Huffy Lawn Tractors Huffy Fairlane 1010 Specification Unit Converter

Convert power, fluid capacities, and operating weights between metric and imperial standards for Huffy Lawn Tractors Huffy Fairlane 1010.

Converted Equivalents:

Horsepower (HP)5 hp
Kilowatts (kW)3.7 kW
Metric Horsepower (PS / CV)5.1 PS
