Huffy Ranchero 1030
The Huffy Ranchero 1030 is a tractor produced by Huffy Lawn Tractors. The listed engine power is Gasoline (gross): 5 hp / 3.7 kW. Transmission: 3 forward and 1 reverse. Operating weight: 166 lbs 75 kg.
Engine Power
Gasoline (gross): 5 hp / 3.7 kW
Fuel & Capacities
Gasoline
Transmission
3 forward and 1 reverse
Operating Weight
166 lbs
75 kg
Overview
 | 1971
Lawn tractor |
|---|
Production | |
|---|---|
Manufacturer | Huffy |
Lawn tractor | |
Huffy Ranchero 1030 Engine | |
|---|---|
5HP Briggs & Stratton 1-cyl gasoline | |
Engine details ...  |
Huffy Ranchero 1030 Transmission | |
|---|---|
3-speed gear | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Open operator station. |
Power Take-off (PTO) | |
|---|---|
Mid PTO | independent |
Clutch | manual |
Dimensions & Tires | |
|---|---|
Weight | 166 lbs
75 kg |
Front tire | 10x2.75 |
Rear tire | 12x3.50 |
Full dimensions and tires ...  | |
References | |
|---|---|
 | |
Huffy Leisure Makers published in 1971, by Huffman Manufacturing |
Engine
Engine Detail — Gasoline
Manufacturer | Briggs & Stratton |
Fuel Type | Gasoline |
Configuration | 1-cylinder, air-cooled vertical-shaft |
Power (gross) | 5 hp
3.7 kW |
Starter type | manual recoil |
Transmission
Transmission — 3 forward and 1 reverse belt-driven gear
Type | belt-driven gear |
Gears | 3 forward and 1 reverse |
Dimensions
Huffy Ranchero 1030 Tires | |
|---|---|
Lawn/turf front | 10x2.75 |
Lawn/turf rear | 12x3.50 |
Dimensions | |
|---|---|
Weight | 166 lbs
75 kg |
Attachments
24" Mower deck | |
|---|---|
Type | mid-mount Huffy |
1-blade with manual lift | |
Cutting width | 24 inches
60 cm |
Cut height | 1.5 to 3 inch
3 to 7 cm |
Photos
Huffy Ranchero 1030 tractor photo
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Huffy Lawn Tractors Huffy Ranchero 1030.
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Huffy Lawn Tractors Huffy Ranchero 1030 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Huffy Lawn Tractors Huffy Ranchero 1030.
Converted Equivalents:
Horsepower (HP)5 hp
Kilowatts (kW)3.7 kW
Metric Horsepower (PS / CV)5.1 PS
