Hurlimann H-6190 Master
The Hurlimann H-6190 Master is a tractor produced by Hurlimann. It is equipped with a 366.12 ci 6.0 L engine. The rated power output is 189 hp 140.9 kW. Transmission: 27 forward and reverse. Operating weight: 13228 lbs 6000 kg.
Engine Power
189 hp
140.9 kW
Fuel & Capacities
60.8 gal (early)
230.1 L
Transmission
27 forward and reverse
Operating Weight
13228 lbs
6000 kg
Hurlimann H-6190 Master Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1992 - 2001
Master SeriesRow-Crop tractor |
|---|---|
1992 - 2001 | |
Master Series | |
Row-Crop tractor | |
Production | |
|---|---|
Manufacturer | Hurlimann |
Row-Crop tractor | |
Variants | |
|---|---|
190 Racing | similar Lamborghini model |
Hurlimann H-6190 Master Engine | |
|---|---|
SAME 6.0L 6-cyl diesel | |
Fuel tank | 60.8 gal (early)
230.1 L |
95.1 gal (late)
360.0 L | |
Engine details ...  | |
Hurlimann H-6190 Master Transmission | |
|---|---|
27-speed 9-speed power shift | |
Transmission details ...  |
Hurlimann H-6190 Master Power | |
|---|---|
Engine | 189 hp
140.9 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Power steering | |
Hydraulic wet disc brakes | |
Cab standard with air-conditioning. |
Hydraulics | |
|---|---|
Pump flow | 15.9 gpm
60.2 lpm |
Tractor hitch | |
|---|---|
Rear lift | 18963 lbs
8601 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Clutch | electro-hydraulic wet disc |
Rear PTO Type | 1000 |
Front PTO | independent OptOptional |
Front PTO Type | 1000 |
Dimensions & Tires | |
|---|---|
Wheelbase | 112.2 inches
284 cm |
Weight | 13228 lbs
6000 kg |
Front tire | 16.9R30 |
Rear tire | 20.8R38 |
Full dimensions and tires ...  | |
Engine
Engine Detail — 366.12 ci / 6.0 L Diesel
Manufacturer | SAME 1000.6 |
Configuration | turbocharged diesel, 6-cylinder, liquid-cooled |
Displacement | 366.12 ci
6.0 L |
Bore/Stroke | 4.13x4.55 inches
105 x 116 mm |
Power | 189 hp
140.9 kW |
Rated RPM | 2350 |
Torque | 483.9 lb-ft
656.2 Nm |
Torque RPM | 1350 |
Starter type | electric |
Transmission
Transmission — 27 forward and reverse 9-speed power shift
Type | 9-speed power shift |
Gears | 27 forward and reverse |
Clutch | electro-hydraulic wet disc |
Nine power shift gears in three ranges. Synchronized shuttle. | |
With 20.8R38 rear tires and 40 KPH transmission option. Reverse speeds are 9% faster than forward. | |
 | |
Dimensions
Hurlimann H-6190 Master Tires | |
|---|---|
Standard tires (ag) | Front: 16.9R30. Rear: 20.8R38 |
Optional tires (ag) | Front: 480/70R30. Rear: 580/70R38 |
Front: 480/70R30. Rear: 650/75R34 | |
Dimensions | |
|---|---|
Wheelbase | 112.2 inches
284 cm |
Length | 177.6 inches
451 cm |
187 inches (with hitch)
474 cm | |
Width | 92.9 inches*Minimum width.
235 cm |
Height (hood) | 75.6 inches
192 cm |
Height (cab) | 114.2 inches
290 cm |
Weight | 13228 lbs
6000 kg |
Ground clearance | 20.3 inches
51 cm |
Front tread | 74.8 to 98.4 inches
189 to 249 cm |
Rear tread | 72.1 to 100.4 inches
183 to 255 cm |
Photos
Hurlimann H-6190 Master tractor photo
