International Harvester 886B
The International Harvester 886B is a tractor produced by International Harvester. It is equipped with a 358 ci 5.9 L engine. The rated power output is 121 hp 90.2 kW. Transmission: International Harvester Torque Amplifier. Operating weight: 12059 lbs 5469 kg.
Engine Power
121 hp
90.2 kW
Fuel & Capacities
Diesel
Transmission
International Harvester Torque Amplifier
Operating Weight
12059 lbs
5469 kg
International Harvester 886B Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1981 - 1982
86B SeriesRow-Crop tractor |
|---|---|
1981 - 1982 | |
86B Series | |
Row-Crop tractor | |
Production | |
|---|---|
Manufacturer | International Harvester |
Row-Crop tractor | |
Built in Geelong, Australia | |
Total built | 432 |
International Harvester 886B Engine | |
|---|---|
International Harvester 5.9L 6-cyl diesel | |
Engine details ...  |
International Harvester 886B Transmission | |
|---|---|
16-speed two-speed power shift | |
Transmission details ...  |
International Harvester 886B Power | |
|---|---|
Engine | 121 hp
90.2 kW |
Drawbar (claimed) | 86 hp
64.1 kW |
PTO (claimed) | 96 hp
71.6 kW |
Mechanical | |
|---|---|
Two-wheel drive | |
Cab standard. |
Capacity | |
|---|---|
Hydraulic system | 22.5 gal
85.2 L |
Hydraulics | |
|---|---|
Capacity | 22.5 gal
85.2 L |
Rear valves | 2 |
Tractor hitch | |
|---|---|
Rear Type | III |
Rear lift (at ends) | 6272 lbs
2844 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO Type | 540/1000 |
Dimensions & Tires | |
|---|---|
Weight | 12059 lbs
5469 kg |
Front tire | 11.00-16 |
Rear tire | 23.1-34 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
International Harvester Australia: Geelong Works by Sarah Tomac* | |
International Harvester Tractors & Equipment in Australia & New Zealand by Graeme Quick | |
Technical Annual published in 1983, by Power Farming | |
*Publication contains known errors. |
Engine
Engine Detail — 358 ci / 5.9 L Diesel
Manufacturer | International Harvester D-358 |
Fuel Type | Diesel |
Configuration | 6-cylinder, liquid-cooled |
Displacement | 358 ci
5.9 L |
Bore/Stroke | 3.875x5.0625 inches
98 x 129 mm |
Power | 121 hp
90.2 kW |
Fuel system | direct injection |
Rated RPM | 2500 |
Torque | 258.2 lb-ft
350.1 Nm |
Torque RPM | 1600 |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission — International Harvester Torque Amplifier
Transmission | International Harvester Torque Amplifier |
Type | two-speed power shift |
Gears | 16 forward and 8 reverse |
Dimensions
International Harvester 886B Tires | |
|---|---|
Standard tires (ag) | Front: 11.00-16. Rear: 23.1-34 |
Dimensions | |
|---|---|
Length | 159.8 inches
405 cm |
Width | 101.6 inches
258 cm |
Shipping weight | 12059 lbs
5469 kg |
Ground clearance | 21 inches
53 cm |
Photos
International Harvester 886B tractor photo
