International Harvester A-886
The International Harvester A-886 is a tractor produced by International Harvester. It is equipped with a 358 ci 5.9 L engine. The rated power output is 121 hp 90.2 kW. Transmission: Torque Amplifier. Operating weight: 11700 lbs 5307 kg.
Engine Power
121 hp
90.2 kW
Fuel & Capacities
Diesel
Transmission
Torque Amplifier
Operating Weight
11700 lbs
5307 kg
International Harvester A-886 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1978 - 1981
86A SeriesRow-Crop tractor |
|---|---|
1978 - 1981 | |
86A Series | |
Row-Crop tractor | |
Production | |
|---|---|
Manufacturer | International Harvester |
Row-Crop tractor | |
Built in Geelong, Australia | |
Total built | 826 |
International Harvester A-886 Engine | |
|---|---|
International Harvester 5.9L 6-cyl diesel | |
Engine details ...  |
International Harvester A-886 Transmission | |
|---|---|
16-speed two-speed power shift | |
Transmission details ...  |
International Harvester A-886 Power | |
|---|---|
Engine | 121 hp
90.2 kW |
Drawbar (claimed) | 86A hp
64.1 kW |
PTO (claimed) | 96 hp
71.6 kW |
Mechanical | |
|---|---|
Two-wheel drive | |
Final drives | bull gear |
Differential lock | electro-hydraulic rear |
Power steering | |
Hydraulic disc brakes | |
Cab standard with air-conditioning. | |
Dimensions & Tires | |
|---|---|
Wheelbase | 105 inches
266 cm |
Weight | 11700 lbs
5307 kg |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Batteries | 2 |
Battery volts | 12 |
References | |
|---|---|
 | |
International Harvester Australia: Geelong Works by Sarah Tomac* | |
International Harvester Tractors & Equipment in Australia & New Zealand by Graeme Quick | |
Technical Annual published in 1981, by Power Farming | |
*Publication contains known errors. |
Engine
Engine Detail — 358 ci / 5.9 L Diesel
Manufacturer | International Harvester D-358 |
Fuel Type | Diesel |
Configuration | 6-cylinder, liquid-cooled inline |
Displacement | 358 ci
5.9 L |
Bore/Stroke | 3.875x5.0625 inches
98 x 129 mm |
Power | 121 hp
90.2 kW |
Rated RPM | 2500 |
Torque | 258 lb-ft
349.8 Nm |
Torque RPM | 1600 |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission — Torque Amplifier
Transmission | Torque Amplifier |
Type | two-speed power shift |
Gears | 16 forward and 8 reverse |
Clutch | 305mm cerametallic disc |
Dimensions
International Harvester A-886 Tires |
|---|
Dimensions | |
|---|---|
Wheelbase | 105 inches
266 cm |
Length | 159 inches
403 cm |
Width | 102 inches
259 cm |
Height (cab) | 114 inches
289 cm |
Shipping weight | 11700 lbs
5307 kg |
Ground clearance | 15 inches
38 cm |
