International Harvester A-986
The International Harvester A-986 is a tractor produced by International Harvester. It is equipped with a 358 ci 5.9 L engine. The rated power output is 133 hp 99.2 kW. Transmission: Torque Amplifier. Operating weight: 12200 lbs 5533 kg.
Engine Power
133 hp
99.2 kW
Transmission
Torque Amplifier
Operating Weight
12200 lbs
5533 kg
International Harvester A-986 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1978 - 1981
86A SeriesRow-Crop tractor |
|---|---|
1978 - 1981 | |
86A Series | |
Row-Crop tractor | |
Production | |
|---|---|
Manufacturer | International Harvester |
Row-Crop tractor | |
Built in Geelong, Australia | |
Total built | 492 |
International Harvester A-986 Engine | |
|---|---|
International Harvester 5.9L 6-cyl diesel | |
Engine details ...  |
International Harvester A-986 Transmission | |
|---|---|
16-speed two-speed power shift | |
Transmission details ...  |
International Harvester A-986 Power | |
|---|---|
Engine | 133 hp
99.2 kW |
Drawbar (claimed) | 103 hp
76.8 kW |
PTO (claimed) | 115 hp
85.8 kW |
Mechanical | |
|---|---|
Two-wheel drive | |
Final drives | bull gear |
Differential lock | electro-hydraulic rear |
Power steering | |
Hydraulic disc brakes | |
Cab standard with air-conditioning. | |
Dimensions & Tires | |
|---|---|
Wheelbase | 105 inches
266 cm |
Weight | 12200 lbs
5533 kg |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Batteries | 2 |
Battery volts | 12 |
References | |
|---|---|
 | |
International Harvester Australia: Geelong Works by Sarah Tomac* | |
International Harvester Tractors & Equipment in Australia & New Zealand by Graeme Quick | |
Technical Annual published in 1981, by Power Farming | |
*Publication contains known errors. |
Engine
Engine Detail — 358 ci / 5.9 L Diesel
Manufacturer | International Harvester DT-358 |
Configuration | turbocharged diesel, 6-cylinder, liquid-cooled inline |
Displacement | 358 ci
5.9 L |
Bore/Stroke | 3.875x5.0625 inches
98 x 129 mm |
Power | 133 hp
99.2 kW |
Rated RPM | 2500 |
Torque | 332 lb-ft
450.2 Nm |
Torque RPM | 1600 |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission — Torque Amplifier
Transmission | Torque Amplifier |
Type | two-speed power shift |
Gears | 16 forward and 8 reverse |
Clutch | 356mm cerametallic disc |
Dimensions
International Harvester A-986 Tires |
|---|
Dimensions | |
|---|---|
Wheelbase | 105 inches
266 cm |
Length | 159 inches
403 cm |
Width | 102 inches
259 cm |
Height (cab) | 114 inches
289 cm |
Shipping weight | 12200 lbs
5533 kg |
Ground clearance | 15 inches
38 cm |
