International Harvester 1046
The International Harvester 1046 is a tractor produced by International Harvester. It is equipped with a 358 ci 5.9 L engine. The rated power output is 108.5 hp 80.9 kW. Transmission: 16 forward and 7 reverse. Operating weight: 8929 to 9700 pounds.
Engine Power
108.5 hp
80.9 kW
Fuel & Capacities
29.1 gal
110.1 L
Transmission
16 forward and 7 reverse
Operating Weight
8929 to 9700 pounds
International Harvester 1046 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1971 - 1978
Row-Crop tractor |
|---|---|
1971 - 1978 | |
Row-Crop tractor | |
Production | |
|---|---|
Manufacturer | International Harvester |
Row-Crop tractor | |
Built in Neuss, Germany | |
International Harvester 1046 Engine | |
|---|---|
International Harvester 5.9L 6-cyl diesel | |
Fuel tank | 29.1 gal
110.1 L |
Engine details ...  | |
International Harvester 1046 Power | |
|---|---|
Engine (gross) | 108.5 hp
80.9 kW |
PTO (claimed) | 93.9 hp
70.0 kW |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Power steering |
Hydraulics | |
|---|---|
Pump flow | 10 gpm
37.9 lpm |
Tractor hitch | |
|---|---|
Rear Type | II |
Rear lift | 6615 lbs
3000 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO Type | 540/1000 |
Dimensions & Tires | |
|---|---|
Wheelbase | 102 inches
259 cm |
Weight | 8929 to 9700 pounds |
Front tire | 7.50x20 |
2WD Rear tire | 18.4/15x38 |
Full dimensions and tires ...  | |
References | |
|---|---|
 | |
1046 published in 1973, by International Harvester |
Engine
Engine Detail — 358 ci / 5.9 L Diesel
Manufacturer | International Harvester D-358 |
Fuel Type | Diesel |
Configuration | 6-cylinder, liquid-cooled |
Displacement | 358 ci
5.9 L |
Bore/Stroke | 3.875x5.0625 inches
98 x 129 mm |
Power (gross) | 108.5 hp
80.9 kW |
Compression | 16:1 |
Rated RPM | 2100 |
Starter volts | 12 |
Oil capacity | 14.8 qts
14.0 L |
Coolant capacity | 28.5 qts
27.0 L |
Transmission
Transmission options | |
|---|---|
12-speed | |
16-speed |
Transmission — 12 forward and 5 reverse
Gears | 12 forward and 5 reverse |
 | |
Transmission — 16 forward and 7 reverse
Gears | 16 forward and 7 reverse |
Dimensions
International Harvester 1046 Tires | |
|---|---|
2WD Standard tires (ag) | Front: 7.50x20. Rear: 18.4/15x38 |
4WD Standard tires (ag) | Front: 11.25/13x24. Rear: 18.4/15x38 |
2WD Optional tires (ag) | Front: 7.50x18. Rear: 18.4/15x34 |
4WD Optional tires (ag) | Front: 11.2/10x28. Rear: 18.4/15x38 |
Dimensions | |
|---|---|
Wheelbase | 102 inches
259 cm |
Length | 154.7 inches
392 cm |
Width | 81.9 inches
208 cm |
Height (hood) | 59.8 inches
151 cm |
2WD Weight | 8929 lbs
4050 kg |
4WD Weight | 9700 lbs
4399 kg |
Ground clearance | 15.4 inches
39 cm |
Front tread | 59.5 to 71.7 inches
151 to 182 cm |
Rear tread | 63.8 to 83.5 inches
162 to 212 cm |
Photos
1971 International 1046.
1971 International 1046.
