Iseki TF23F

The Iseki TF23F is a tractor produced by Iseki. It is equipped with a 87.2 ci 1.4 L engine. The rated power output is 22.7 hp 16.9 kW. Transmission: 9 forward and 3 reverse. Operating weight: 1940 lbs 879 kg.

Overview

	1995 - ???? Sial SeriesCompact Utility tractor
1995 - ????
Sial Series
Compact Utility tractor

1995 - ????
Sial Series
Compact Utility tractor

Production
Manufacturer	Iseki
Compact Utility tractor

Variants
TF23F-U	utility
TF23HF	high-crop
TF23NF	narrow

Iseki TF23F Engine
Iseki 1.4L 3-cyl diesel
Fuel tank	6.3 gal 23.8 L
Engine details ...

Iseki TF23F Transmission
9-speed
Transmission details ...

Iseki TF23F Power
Engine	22.7 hp 16.9 kW
PTO (claimed)	20.4 hp 15.2 kW

Mechanical
Four-wheel drive
Two-post ROPS with canopy. Cab optional. Two-post folding ROPS on TF23NF.

Photos
Iseki TF23F photos...

Power Take-off (PTO)
Rear PTO Type	540 (1.375)
Engine RPM	524@2500
	730@2500
	1269@2500

Dimensions & Tires
Wheelbase	59.8 inches 151 cm
Weight	1940 lbs 879 kg
Front tire	7-14
Rear tire	9.5-24
Full dimensions and tires ...

Electrical
Ground	negative
Battery volts	12
Battery AH	55

Engine

	1995 - ???? Sial SeriesCompact Utility tractor
1995 - ????
Sial Series
Compact Utility tractor

1995 - ????
Sial Series
Compact Utility tractor

Engine Detail
Iseki E3CE
diesel
3-cylinder
liquid-cooled
Displacement	87.2 ci 1.4 L
Bore/Stroke	3.35x3.31 inches 85 x 84 mm
Power	22.7 hp 16.9 kW
Rated RPM	2500
Starter	electric
Starter volts	12

Transmission

	1995 - ???? Sial SeriesCompact Utility tractor
1995 - ????
Sial Series
Compact Utility tractor

1995 - ????
Sial Series
Compact Utility tractor

Transmission
Gears	9 forward and 3 reverse

Dimensions

	1995 - ???? Sial SeriesCompact Utility tractor
1995 - ????
Sial Series
Compact Utility tractor

1995 - ????
Sial Series
Compact Utility tractor

Iseki TF23F Tires
Standard tires (ag)	Front: 7-14. Rear: 9.5-24
TF23HF Optional tires (ag)	Front: 7-14. Rear: 8.3-26
TF23HF Optional tires (ag)	Front: 7-14. Rear: 9.5-24
TF23NF Optional tires (ag)	Front: 6-12. Rear: 9.5-22

Dimensions
Wheelbase	59.8 inches 151 cm
Length	109.8 inches 278 cm
Width	45.3 inches 115 cm
Height	77.4 inches 196 cm
Weight	1940 lbs 879 kg
Ground clearance	13.8 inches 35 cm
Front tread	37.8 inches 96 cm
Rear tread	34.7 to 40.8 inches 88 to 103 cm

Photos

Iseki TF23F

Iseki TF23F with tiller, rear view.
