Iseki TS1610
The Iseki TS1610 is a tractor produced by Iseki. It is equipped with a 59.5 ci 1.0 L engine. The rated power output is 15.8 hp 11.8 kW. Transmission: 18 forward and 6 reverse. Operating weight: 1653 to 1863 pounds.
Engine Power
15.8 hp
11.8 kW
Fuel & Capacities
4.2 gal
15.9 L
Transmission
18 forward and 6 reverse
Operating Weight
1653 to 1863 pounds
Iseki TS1610 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | TS SeriesCompact Utility tractor |
|---|---|
TS Series | |
Compact Utility tractor | |
Production | |
|---|---|
Manufacturer | Iseki |
Compact Utility tractor | |
Variants | |
|---|---|
TS1610F | 4WD |
Iseki TS1610 Engine | |
|---|---|
Isuzu 1.0L 2-cyl diesel | |
Fuel tank | 4.2 gal
15.9 L |
Engine details ...  | |
Iseki TS1610 Power | |
|---|---|
Engine | 15.8 hp
11.8 kW |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Open operator station. |
Tractor hitch | |
|---|---|
Rear Type | I |
Power Take-off (PTO) | |
|---|---|
Rear PTO Type | 540 (1.375) |
Engine RPM | 2300@537 |
2300@711 | |
2300@890 | |
2300@1274 | |
Dimensions & Tires | |
|---|---|
2WD Wheelbase | 52.8 inches
134 cm |
4WD Wheelbase | 54.3 inches
137 cm |
Weight | 1653 to 1863 pounds |
Front tire | 4.00-12 |
2WD Rear tire | 8.3/8-22 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
TS & TX Series published in 1975, by Iseki | |
TS1610G published by Iseki |
Engine
Engine Detail — 59.5 ci / 1.0 L Diesel
Manufacturer | Isuzu 2AA1 |
Fuel Type | Diesel |
Configuration | 2-cylinder, liquid-cooled |
Displacement | 59.5 ci
1.0 L |
Bore/Stroke | 3.39x3.31 inches
86 x 84 mm |
Power | 15.8 hp
11.8 kW |
Rated RPM | 2300 |
Starter | electric |
Starter volts | 12 |
Oil capacity | 3.8 qts
3.6 L |
Iseki TS1610 Engine | |
|---|---|
 |
Transmission
Transmission options | |
|---|---|
9-speed gear | |
18-speed creeper |
Transmission — 9 forward and 3 reverse gear
Type | gear |
Gears | 9 forward and 3 reverse |
Three gears (1-3) plus reverse (R) in three ranges. Additional creeper range available on four-wheel drive models. | |
 | |
Transmission | |
Type | creeper |
Gears | 18 forward and 6 reverse |
 | |
Dimensions
Iseki TS1610 Tires | |
|---|---|
2WD Standard tires (ag) | Front: 4.00-12. Rear: 8.3/8-22 |
4WD Standard tires (ag) | Front: 6-14. Rear: 8.3/8-22 |
Dimensions | |
|---|---|
2WD Wheelbase | 52.8 inches
134 cm |
4WD Wheelbase | 54.3 inches
137 cm |
2WD Length | 89 inches
226 cm |
4WD Length | 89.4 inches
227 cm |
2WD Width | 42.9 inches
108 cm |
4WD Width | 44.1 inches
112 cm |
2WD Height | 75.2 inches
191 cm |
4WD Height | 76 inches
193 cm |
2WD Weight | 1653 lbs
749 kg |
4WD Weight | 1863 lbs
845 kg |
2WD Ground clearance | 11.4 inches
28 cm |
4WD Ground clearance | 10.2 inches
25 cm |
Front tread | 33.5 to 37.4 inches
85 to 94 cm |
Rear tread | 33.5 to 39.4 inches
85 to 100 cm |
Photos
Iseki TS1610
Iseki TS1610
Iseki TS1610
