John Deere 1030

The John Deere 1030 is a tractor produced by John Deere. It is equipped with a 164.4 ci 2.7 L engine. The rated power output is 45.6 hp 34.0 kW. Transmission: 16 forward and 8 reverse. Operating weight: 5954 lbs 2700 kg.

Overview

	1973 - 1979 Utility tractor
1973 - 1979
Utility tractor

Production
Manufacturer	John Deere
Utility tractor
Built in Mannheim, Baden-Württemberg, Germany

John Deere 1030 Engine
John Deere 2.7L 3-cyl diesel
Fuel tank	16.4 gal 62.1 L
Engine details ...

John Deere 1030 Power
Engine (gross)	48.3 hp 36.0 kW
Engine (net)	45.6 hp 34.0 kW
PTO (claimed)	38.9 hp 29.0 kW

Mechanical
Two-wheel drive
Final drives	planetary
Differential lock	mechanical rear
Steering	manual
Steering	power OptOptional
Hydraulic wet disc brakes
Open operator station.

Hydraulics
Type	closed center
Pressure	2248 psi 155.0 bar
Pump flow	6.6 gpm 25.0 lpm
	12.4 gpmOptOptional 46.9 lpm

Tractor hitch
Rear Type	II/I
Control	position control and lower-link draft sensing
Rear lift	4024 lbs 1825 kg

Power Take-off (PTO)
Rear PTO	live
Rear PTO Type	540 (1.375)
Engine RPM	540@2100

Dimensions & Tires
Wheelbase	80.7 inches 204 cm
Weight	4720 to 5954 pounds
Front tire	6.50-16
Rear tire	12.4-36
Full dimensions and tires ...

Electrical
Ground	negative
Charging system	alternator
Charging amps	28
Batteries	2
Battery volts	12
Battery AH	55

References
Operator's Manual 145 Loader (OMW21474)
1030 Tractor published in 1977, by John Deere
Tractors 40 to 80 hp published in 1978, by John Deere
Product Information Manual published in 1975, by John Deere
Product Information Manual published in 1977, by John Deere

Engine

Engine Detail — 164.4 ci / 2.7 L Diesel

Manufacturer	John Deere
Fuel Type	Diesel
Configuration	3-cylinder, liquid-cooled
Displacement	164.4 ci 2.7 L
Bore/Stroke	4.02x4.33 inches 102 x 110 mm
Power (net)	45.6 hp 34.0 kW
Power (gross)	48.3 hp 36.0 kW
Air cleaner	dry
Compression	16.2:1
Rated RPM	2500
Idle RPM	650-2650
Operating RPM	1400-2500
Torque	112 lb-ft 151.9 Nm
Torque RPM	1400
Firing order	1-2-3
Starter	electric
Starter volts	12
Oil capacity	6 qts 5.7 L
Coolant capacity	11 qts 10.4 L

Transmission

Transmission options
8-speed gear
16-speed

Transmission — 8 forward and 4 reverse gear

Type	gear
Gears	8 forward and 4 reverse
Clutch	dry disc
Oil capacity	38 qts 36.0 L

Transmission — 16 forward and 8 reverse

Gears

16 forward and 8 reverse

Dimensions

John Deere 1030 Tires
Ag front	6.50-16
Ag rear	12.4-36

Dimensions
Wheelbase	80.7 inches 204 cm
Length	133 inches 337 cm
Width	65.9 inches 167 cm
Weight	5954 lbs 2700 kg
Shipping weight	4720 lbs 2140 kg
Front tread	49.6 to 75.8 inches 125 to 192 cm
Rear tread	53.2 to 76.8 inches 135 to 195 cm

John Deere 1030 Height
Hood	52.8 inches 134 cm
ROPS	90.9 inches 230 cm
Exhaust	78.3 inches 198 cm
