Massey-Harris 202
The Massey-Harris 202 is a tractor produced by Massey Harris. It is equipped with a 290 ci 4.8 L engine. Transmission: 4 forward and 1 reverse. Operating weight: 6700 lbs 3039 kg.
Fuel & Capacities
Gasoline
Transmission
4 forward and 1 reverse
Operating Weight
6700 lbs
3039 kg
Massey Harris Massey-Harris 202 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1940 - 1942
200 SeriesStandard-tread tractor |
|---|---|
1940 - 1942 | |
200 Series | |
Standard-tread tractor | |
Production | |
|---|---|
Manufacturer | Massey-Harris |
Standard-tread tractor | |
Built in Racine, Wisconsin, USA | |
Total built | 223 |
Original price was $1,900 in 1942 | |
Variants | |
|---|---|
201 | Chrysler 4.1L gas |
202 | Continental 4.8L gas |
203 | Continental 5.4L distillate |
203G | Continental 5.4L gas |
Massey-Harris 202 Engine | |
|---|---|
Continental 4.8L 6-cyl gasoline | |
Engine details ...  |
Massey-Harris 202 Transmission | |
|---|---|
4-speed gear | |
Transmission details ...  |
Massey-Harris 202 Power | |
|---|---|
PTO (claimed) | 37 hp
27.6 kW |
Plows | 5 |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Open operator station. |
Power Take-off (PTO) | |
|---|---|
Rear PTO Type | 540 |
Dimensions & Tires | |
|---|---|
Weight | 6700 lbs
3039 kg |
Full dimensions and tires ...  | |
Belt Pulley | |
|---|---|
Diameter | 13.5 inches
34 cm |
Width | 8 inches
20 cm |
RPM | 839 |
Speed | 2962 ft/min
902.82 meters/min |
References | |
|---|---|
 | |
Two Powerful New Tractors... published in 1941, by Massey-Harris |
Engine
Engine Detail — 290 ci / 4.8 L Gasoline
Manufacturer | Continental M292 |
Fuel Type | Gasoline |
Configuration | 6-cylinder, liquid-cooled |
Displacement | 290 ci
4.8 L |
Transmission
Transmission — 4 forward and 1 reverse gear
Type | gear |
Gears | 4 forward and 1 reverse |
Clutch | mechanical dry disc |
 | |
Dimensions
Massey-Harris 202 Tires |
|---|
Dimensions | |
|---|---|
Weight | 6700 lbs
3039 kg |
Photos
Massey-Harris 202 tractor photo
