john deere 1530

John Deere 1530 tractor photo
1973 - 1975 Generation II SeriesUtility tractor
1973 - 1975
Generation II Series
Utility tractor
1973 - 1975
Generation II Series
Utility tractor
1973 - 1975
Generation II Series
Utility tractor
Nebraska Tractor Test 1147
1530 fuel use from test 1147
1530 fuel use from test 1147
1530 fuel use from test 1147
1530 fuel use from test 1147
Nebraska Tractor Test 1147
Diesel 16-speed 2WD October 13 - 18, 1973 Link: Nebraska Tractor Test 1147 file
PTO performance
Power at rated engine speed
45.38 hp 33.8 kW
Fuel use
3.3 gal/hour 12.5 l/hour
Power at rated PTO speed
41.36 hp 30.8 kW
Fuel use
2.9 gal/hour 11.0 l/hour
Drawbar performance
Max power
38.07 hp 28.4 kW
Fuel use
3.2 gal/hour 12.1 l/hour
Gear 5H used for power test.
Max pull
5,139 lbs 2331 kg
Gear 3L used for pull test.
