Kioti DK55
The Kioti DK55 is a tractor produced by Kioti. It is equipped with a 134.1 ci 2.2 L engine. The listed engine power is Diesel (gross): 55 hp / 41.0 kW. Transmission: 12 forward and reverse. Operating weight: 4685 to 5105 pounds.
Engine Power
Diesel (gross): 55 hp / 41.0 kW
Fuel & Capacities
18 gal
68.1 L
Transmission
12 forward and reverse
Operating Weight
4685 to 5105 pounds
Overview
 | 2003 - 2007
DK SeriesCompact Utility tractor
DK Series
Compact Utility tractor |
|---|
Production | |
|---|---|
Manufacturer | Kioti (a part of Daedong) |
Compact Utility tractor | |
Built in Daegu, South Korea | |
Kioti DK55 Engine | |
|---|---|
Daedong 2.2L 4-cyl diesel | |
Fuel tank | 18 gal
68.1 L |
Engine details ...  | |
Kioti DK55 Transmission | |
|---|---|
12-speed synchronized shuttle | |
Transmission details ...  |
Kioti DK55 Power | |
|---|---|
Engine (gross) | 55 hp
41.0 kW |
PTO (claimed) | 45.2 hp
33.7 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Differential lock | mechanical rear |
Power steering | |
Wet disc brakes | |
Two-post folding ROPS. Optional canopy. Optional cab with air-conditioning. | |
Hydraulics | |
|---|---|
Pump flow | 9.9 gpm
37.5 lpm |
Total flow | 14.2 gpm
53.7 lpm |
Steering flow | 4.2 gpm
15.9 lpm |
Tractor hitch | |
|---|---|
Rear Type | II/I |
Rear lift (at 24"/610mm) | 2,643 lbs
1198 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/1000 |
Dimensions & Tires | |
|---|---|
Wheelbase | 76.8 inches
195 cm |
Weight | 4685 to 5105 pounds |
Front tire | 9.5-20/6 |
Rear tire | 14.9-28 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
New model 55HP Tractor DK55/C published by Kioti |
Engine
Engine Detail — 134.1 ci / 2.2 L Diesel
Manufacturer | Daedong 4A220T |
Configuration | turbocharged diesel, 4-cylinder, liquid-cooled |
Displacement | 134.1 ci
2.2 L |
Bore/Stroke | 3.425x3.628 inches
87 x 92 mm |
Power (gross) | 55 hp
41.0 kW |
Pre-heating | glow plugs |
Rated RPM | 2600 |
Starter volts | 12 |
Transmission
Transmission — 12 forward and reverse synchronized shuttle
Type | synchronized shuttle |
Gears | 12 forward and reverse |
Clutch | dry disc |
 | |
Dimensions
Kioti DK55 Tires | |
|---|---|
Ag front | 9.5-20/6 |
Ag rear | 14.9-28 |
Lawn/turf front | 29x12.5x15/6 |
Lawn/turf rear | 21.5Lx16.1/4 |
Industrial front | 12x16.5/6 |
Industrial rear | 17.5x24/8 |
Dimensions | |
|---|---|
Wheelbase | 76.8 inches
195 cm |
Length | 128.6 inches
326 cm |
Width | 69.3 inches
176 cm |
Height (ROPS) | 106.5 inches
270 cm |
Height (Folded ROPS) | 85.5 inches
217 cm |
Height (cab) | 104 inches
264 cm |
ROPS Weight | 4685 lbs
2125 kg |
Cab Weight | 5105 lbs
2315 kg |
Ground clearance | 17.5 inches
44 cm |
Front tread | 57.5 inches
146 cm |
Rear tread | 53.9 to 61.6 inches
136 to 156 cm |
Attachments
Attachment overview | |
|---|---|
Front-end loader | |
Backhoe |
Kioti KB2385 Backhoe | |
|---|---|
Backhoe type | Kioti KB2385 Backhoe |
Photos
Kioti DK55 tractor photo
Recommended Implements & Sizing Guide
Engineering recommendations for Kioti DK55 based on its 55 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 3 to 4 Bottom (16")3 - 4 铧 (40 cm) | Heavy Duty | Suitable for medium loam and stubble turnover. |
Rotary Cutter / MowerMowing & Clearing | 6 ft (72 in)1.8 m | Medium Duty | Medium pasture clearing; rear slip-clutch recommended. |
Rotary TillerSeedbed Prep | 66 to 72 in165 - 180 cm | Medium Duty | Standard utility tiller; slip clutch protection required. |
Disc HarrowSecondary Tillage | 7 to 8 ft Tandem Disc2.1 - 2.4 m 对开双排耙 | Medium Duty | Field leveling and clod breaking behind plows. |
Hay BalerHay & Forage | Small Square Baler (14x18")小方捆打捆机 (36x46 cm) | Medium Duty | Classic 2-string baler for horse and small livestock hay. |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Kioti DK55.
Estimated Continuous Field Runtime: 6.3 hrs
Approximately 6.3 hours of continuous field operation at ~75% rated power on a full tank (18 gal / 68.1 L).
Estimated 75% Load Fuel Burn~2.9 gal/hr (10.8 L/hr)
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Kioti DK55 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Kioti DK55.
Converted Equivalents:
Horsepower (HP)55 hp
Kilowatts (kW)41 kW
Metric Horsepower (PS / CV)55.8 PS
Direct Competitor Comparison
Compare Kioti DK55 against same-era industry alternatives in the same horsepower class.
Current Model
Kioti
Kioti DK55
Engine Power:Diesel (gross): 55 hp / 41.0 kW
★ Baseline Reference
