Kioti NS4710
The Kioti NS4710 is a tractor produced by Kioti. It is equipped with a 111.4 ci 1.8 L engine. The listed engine power is Diesel (gross): 44.9 hp / 33.5 kW. Transmission: infinite forward and reverse (3-range). Operating weight: 1102 lbs 499 kg.
Engine Power
Diesel (gross): 44.9 hp / 33.5 kW
Fuel & Capacities
13.2 gal
50.0 L
Transmission
infinite forward and reverse (3-range)
Operating Weight
1102 lbs
499 kg
Overview
 | 2022 -
NS SeriesCompact Utility tractor |
|---|---|
2022 - | |
NS Series | |
Compact Utility tractor | |
Production | |
|---|---|
Manufacturer | Kioti (a part of Daedong) |
Compact Utility tractor | |
Kioti NS4710 Engine | |
|---|---|
Daedong 1.8L 3-cyl diesel | |
Fuel tank | 13.2 gal
50.0 L |
Engine details ...  | |
Kioti NS4710 Power | |
|---|---|
Engine (gross) | 44.9 hp
33.5 kW |
PTO (claimed) | 36.6 hp
27.3 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Differential lock | mechanical rear |
Power steering | |
Two-post folding ROPS. Cab optional. | |
Hydraulics | |
|---|---|
Type | open center |
Valves | 1 or 2 |
Total flow | 16.5 gpm
62.5 lpm |
Tractor hitch | |
|---|---|
Rear Type | I |
Control | position and draft control |
Rear lift (at 24"/610mm) | 2493 lbs
1130 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540 (1.375) |
Engine RPM | 2000 |
Dimensions & Tires | |
|---|---|
Wheelbase | 75.5 inches
191 cm |
Weight | 4027 lbs
1826 kg |
Front tire | 8-16 |
Rear tire | 13.6-24 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
NS Series published in 2022, by Kitoi |
Engine
Engine Detail — 111.4 ci / 1.8 L Diesel
Manufacturer | Daedong |
Configuration | turbocharged diesel, 3-cylinder, liquid-cooled inline |
Displacement | 111.4 ci
1.8 L |
Bore/Stroke | 3.43x4.03 inches
87 x 102 mm |
Emissions | Tier IV |
Power (gross) | 44.9 hp
33.5 kW |
Rated RPM | 2600 |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission options | |
|---|---|
12-speed shuttle | |
hydrostatic |
Transmission — 12 forward and reverse shuttle
Type | shuttle |
Gears | 12 forward and reverse |
Clutch | dry disc |
Transmission — infinite forward and reverse (3-range) hydrostatic
Type | hydrostatic |
Gears | infinite forward and reverse (3-range) |
Dimensions
Kioti NS4710 Tires | |
|---|---|
Standard tires (ag) | Front: 8-16. Rear: 13.6-24 |
Lawn/turf front | 29x12.5-15 |
Lawn/turf rear | 21.5-16.1 |
Industrial front | 10-16.5 |
Industrial rear | 14.9-24 |
Dimensions | |
|---|---|
Wheelbase | 75.5 inches
191 cm |
Length | 136.4 inches
346 cm |
Width | 67.1 inches
170 cm |
Height (ROPS) | 98.4 inches
249 cm |
Weight | 4027 lbs
1826 kg |
Ground clearance | 13.4 inches
34 cm |
Front tread | 51.1 inches
129 cm |
Rear tread | 54.3 inches
137 cm |
Attachments
Attachment overview | |
|---|---|
Front-end loader | |
Backhoe |
Kioti KB2485 Backhoe | |
|---|---|
Backhoe type | Kioti KB2485 Backhoe |
Weight | 1102 lbs
499 kg |
Transport height | 92.9 inches
235 cm |
2-Foot flat digging depth | 94.4 inches
239 cm |
Reach from pivot | 136.1 inches
345 cm |
Loading height | 80.3 inches
203 cm |
Bucket Rotation | 180° |
Swing Arc | 180° |
Bucket force | 3748 lbs
1700 kg |
Dipperstick force | 2205 lbs
1000 kg |
Photos
Kioti NS4710 tractor photo
Recommended Implements & Sizing Guide
Engineering recommendations for Kioti NS4710 based on its 44.9 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 2 to 3 Bottom (14-16")2 - 3 铧 (35-40 cm) | Medium Duty | Standard utility farm tillage. |
Rotary Cutter / MowerMowing & Clearing | 6 ft (72 in)1.8 m | Medium Duty | Medium pasture clearing; rear slip-clutch recommended. |
Rotary TillerSeedbed Prep | 66 to 72 in165 - 180 cm | Medium Duty | Standard utility tiller; slip clutch protection required. |
Disc HarrowSecondary Tillage | 7 to 8 ft Tandem Disc2.1 - 2.4 m 对开双排耙 | Medium Duty | Field leveling and clod breaking behind plows. |
Hay BalerHay & Forage | Small Square Baler (14x18")小方捆打捆机 (36x46 cm) | Medium Duty | Classic 2-string baler for horse and small livestock hay. |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Kioti NS4710.
Estimated Continuous Field Runtime: 5.7 hrs
Approximately 5.7 hours of continuous field operation at ~75% rated power on a full tank (13.2 gal / 50 L).
Estimated 75% Load Fuel Burn~2.3 gal/hr (8.8 L/hr)
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Kioti NS4710 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Kioti NS4710.
Converted Equivalents:
Horsepower (HP)44.9 hp
Kilowatts (kW)33.5 kW
Metric Horsepower (PS / CV)45.5 PS
Direct Competitor Comparison
Compare Kioti NS4710 against same-era industry alternatives in the same horsepower class.
Current Model
Kioti
Kioti NS4710
Engine Power:Diesel (gross): 44.9 hp / 33.5 kW
★ Baseline Reference
International HarvesterMarket Competitor
International Harvester 404
Engine Power:40.8
Production Years:1961 - 1968
