Kubota GL200
The Kubota GL200 is a tractor produced by Kubota. It is equipped with a 85 ci 1.4 L engine. The rated power output is 19.7 hp 14.7 kW. Transmission: 16 forward and reverse. Operating weight: 2414 to 2745 pounds.
Engine Power
19.7 hp
14.7 kW
Fuel & Capacities
7.1 gal
26.9 L
Transmission
16 forward and reverse
Operating Weight
2414 to 2745 pounds
Kubota GL200 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1993 - 1995
GL SeriesCompact Utility tractor |
|---|---|
1993 - 1995 | |
GL Series | |
Compact Utility tractor | |
Production | |
|---|---|
Manufacturer | Kubota |
Compact Utility tractor | |
Variants | |
|---|---|
GL200 | ROPS |
GL200Q | cab |
Kubota GL200 Engine | |
|---|---|
Kubota 1.4L 3-cyl diesel | |
Fuel tank | 7.1 gal
26.9 L |
Engine details ...  | |
Kubota GL200 Power | |
|---|---|
Engine | 19.7 hp
14.7 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Power steering | |
Mechanical wet disc brakes | |
Two-post ROPS. Cab optional. |
Tractor hitch | |
|---|---|
Rear Type | I |
Power Take-off (PTO) | |
|---|---|
Rear PTO Type | 546/772/947/1254 (1.375) |
Dimensions & Tires | |
|---|---|
ROPS Wheelbase | 61 inches
154 cm |
Cab Wheelbase | 62.4 inches
158 cm |
Weight | 2414 to 2745 pounds |
Front tire | 6-14 |
Rear tire | 8.3-24 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
Engine
Engine Detail — 85 ci / 1.4 L Diesel
Manufacturer | Kubota D1403 |
Fuel Type | Diesel |
Configuration | 3-cylinder, liquid-cooled |
Displacement | 85 ci
1.4 L |
Bore/Stroke | 3.1x3.6 inches
79 x 91 mm |
Power | 19.7 hp
14.7 kW |
Rated RPM | 2500 |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission options | |
|---|---|
16-speed gear | |
16-speed power shift |
Transmission — 16 forward and reverse gear
Type | gear |
Gears | 16 forward and reverse |
Clutch | dry disc |
Four gears (1-4) in two ranges (low/high) with additional creeper range and shuttle shift. | |
 | |
Transmission — 16 forward and reverse power shift
Type | power shift |
Gears | 16 forward and reverse |
Dimensions
Kubota GL200 Tires | |
|---|---|
Standard tires (ag) | Front: 6-14. Rear: 8.3-24 |
Dimensions | |
|---|---|
ROPS Wheelbase | 61 inches
154 cm |
Cab Wheelbase | 62.4 inches
158 cm |
ROPS Length | 116.1 inches
294 cm |
Cab Length | 118.3 inches
300 cm |
ROPS Width | 49.2 inches
124 cm |
Cab Width | 51.2 inches
130 cm |
Height (ROPS) | 77 inches
195 cm |
Height (cab) | 77.6 inches
197 cm |
ROPS Weight | 2414 lbs
1094 kg |
Cab Weight | 2745 lbs
1245 kg |
Ground clearance | 13.2 inches
33 cm |
Front tread | 37.4 inches
94 cm |
Rear tread | 39.8/44.5 inches
101/113 cm |
