Kubota M126GX
The Kubota M126GX is a tractor produced by Kubota. It is equipped with a 374 ci 6.1 L engine. The listed engine power is Diesel (listed): 125 hp / 93.2 kW. Transmission: Intelli-Shift Creeper. Operating weight: 10373 lbs 4705 kg.
Engine Power
Diesel (listed): 125 hp / 93.2 kW
Fuel & Capacities
50.2 gal
190.0 L
Transmission
Intelli-Shift Creeper
Operating Weight
10373 lbs
4705 kg
Overview
 | 2012 -
Grand X SeriesRow-Crop tractor |
|---|---|
2012 - | |
Grand X Series | |
Row-Crop tractor | |
Production | |
|---|---|
Manufacturer | Kubota |
Row-Crop tractor | |
Original price was $78,152 in 2014 | |
Kubota M126GX Engine | |
|---|---|
Kubota 6.1L 4-cyl diesel | |
Fuel tank | 50.2 gal
190.0 L |
Engine details ...  | |
Kubota M126GX Power | |
|---|---|
Engine | 125 hp
93.2 kW |
PTO (claimed) | 108 hp
80.5 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Differential lock | electro-hydraulic front and rear |
Steering | hydrostatic power |
Hydraulic wet disc brakes | |
Grand X Cab standard with air-conditioning. | |
Hydraulics | |
|---|---|
Valves | 2 to 4 |
Pump flow | 18.7 gpm
70.8 lpm |
Steering flow | 16 gpm
60.6 lpm |
Tractor hitch | |
|---|---|
Rear Type | II |
Control | electronic lower-link draft control |
Rear lift (at 24"/610mm) | 6834 lbs
3099 kg |
9447 lbs (optional)
4285 kg | |
Rear Arms | telescopic lower link ends |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Clutch | hydraulic wet disc |
Rear PTO Type | 540/1000 (1.375) |
Dimensions & Tires | |
|---|---|
Wheelbase | 105.9 inches
268 cm |
Weight | 10373 lbs
4705 kg |
Front tire | 14.9R24 |
Rear tire | 18.4R38 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 80 |
Battery CCA | 1090 |
Battery volts | 12 |
Battery AH | 160 |
Engine
Engine Detail — 374 ci / 6.1 L Diesel
Manufacturer | Kubota V6108-TI-CRS |
Configuration | turbocharged and intercooled diesel, 4-cylinder 16-valve, liquid-cooled |
Displacement | 374 ci
6.1 L |
Bore/Stroke | 4.65x5.51 inches
118 x 140 mm |
Emissions | Interim Tier IV |
Emission control | exhaust gas recirculation and diesel particulate filter (DPF) (EGR) |
Power | 125 hp
93.2 kW |
Fuel system | common rail direct injection |
Air cleaner | dual dry element |
Rated RPM | 2200 |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission options | |
|---|---|
24-speed eight-speed power shift | |
32-speed |
Transmission — Intelli-Shift
Transmission | Intelli-Shift |
Type | eight-speed power shift |
Gears | 24 forward and reverse |
Clutch | electro-hydraulic wet disc |
Eight power shift gears in three ranges. Power shuttle. | |
Transmission — Intelli-Shift Creeper
Transmission | Intelli-Shift Creeper |
Gears | 32 forward and reverse |
Clutch | electro-hydraulic wet disc |
Dimensions
Kubota M126GX Tires | |
|---|---|
Ag front | 14.9R24 |
Ag rear | 18.4R38 |
Dimensions | |
|---|---|
Wheelbase | 105.9 inches
268 cm |
Length | 171.7 inches
436 cm |
Width | 85.8 inches
217 cm |
Height | 113.2 inches
287 cm |
Weight | 10373 lbs
4705 kg |
Ground clearance | 22.2 inches
56 cm |
Front axle | 4WD |
Front tread | 69.9 to 73.8 inches
177 to 187 cm |
Rear tread | 62.6 to 82.3 inches
159 to 209 cm |
Photos
Kubota M126GX
Recommended Implements & Sizing Guide
Engineering recommendations for Kubota M126GX based on its 125 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 4 to 5 Bottom (16-18")4 - 5 铧 (40-45 cm) | Heavy Duty | Heavy primary tillage; semi-mounted hitch recommended. |
Rotary Cutter / MowerMowing & Clearing | 10 to 12 ft Flex-Wing3.0 - 3.6 m 折叠双翼 | Heavy Duty | Wide swath pasture and crop residue shredding. |
Rotary TillerSeedbed Prep | 90 to 120 in Heavy Duty230 - 300 cm 重型旋耕机 | Commercial / Field Scale | Deep intensive seedbed preparation for commercial row crops. |
Disc HarrowSecondary Tillage | 15 to 22 ft Folding Disc4.5 - 6.7 m 折叠式圆盘耙 | Commercial / Field Scale | Wide commercial field leveling; requires hydraulic remotes. |
Hay BalerHay & Forage | 5x6 Round Baler or 3x3 Mid Square1.5x1.8 m 大圆捆或中型方捆机 | Heavy Duty | High density baling; requires minimum 85 PTO HP. |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Kubota M126GX.
Estimated Continuous Field Runtime: 7.7 hrs
Approximately 7.7 hours of continuous field operation at ~75% rated power on a full tank (50.2 gal / 190 L).
Estimated 75% Load Fuel Burn~6.5 gal/hr (24.6 L/hr)
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Kubota M126GX Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Kubota M126GX.
Converted Equivalents:
Horsepower (HP)125 hp
Kilowatts (kW)93.2 kW
Metric Horsepower (PS / CV)126.7 PS
Direct Competitor Comparison
Compare Kubota M126GX against same-era industry alternatives in the same horsepower class.
Current Model
Kubota
Kubota M126GX
Engine Power:Diesel (listed): 125 hp / 93.2 kW
★ Baseline Reference
