Kubota M6-141

The Kubota M6-141 is a tractor produced by Kubota. It is equipped with a 374 ci 6.1 L engine. The rated power output is 133 hp 99.2 kW. Transmission: Intelli-Shift Creeper. Operating weight: 10880 lbs 4935 kg.

Overview

	2015 - M6 SeriesUtility tractor
2015 -
M6 Series
Utility tractor

Production
Manufacturer	Kubota
Utility tractor

Kubota M6-141 Engine
Kubota 6.1L 4-cyl diesel
Fuel tank	50.2 gal 190.0 L
Exhaust fluid (DEF)	5.3 gal 20.1 L
Engine details ...

Kubota M6-141 Power
Engine (gross)	141.4 hp 105.4 kW
Engine (net)	133 hp 99.2 kW
PTO (claimed)	114 hp 85.0 kW
Drawbar (tested)	106.08 hp 79.1 kW
PTO (tested)	126.58 hp 94.4 kW
Performance test details ...

Mechanical
Four-wheel drive
Differential lock	electro-hydraulic front and rear
Power steering
Hydraulic wet disc brakes
Grand X Cab standard with air-condiitoning.

Hydraulics
Valves	2 to 4
Pump flow	20.4 gpm 77.2 lpm
Steering flow	14.5 gpm 54.9 lpm
	17 gpm*With optional front axle suspension. 64.3 lpm

Tractor hitch
Rear Type	II
Control	electronic lower-link draft sensing
Rear lift (at 24"/610mm)	6834 lbs 3099 kg
	9447 lbs*Optional, advertised capacity. Tested lift was 8613 pounds. 4285 kg
Rear Arms	telescopic lower link ends and stabilizers

Power Take-off (PTO)
Rear PTO	independent
Clutch	hydraulic wet disc
Rear PTO Type	540/1000

Dimensions & Tires
Wheelbase	105.9 inches 268 cm
	105.5 inches*With optional front axle suspension. 267 cm
Weight	10880 to 11321 pounds
Front tire	14.9R24
Rear tire	18.4R38
Full dimensions and tires ...

Electrical
Ground	negative
Charging system	alternator
Charging amps	130
Battery volts	12

References
M6-101/M6-111/M6-131/M6-141 published in 2014, by Kubota
M6-101/M6-111/M6-131/M6-141 published in 2021, by Kubota

Engine

Engine Detail — 374 ci / 6.1 L Diesel

Manufacturer	Kubota V6108-TI-CRS
Configuration	turbocharged intercooled diesel, 4-cylinder, liquid-cooled
Displacement	374 ci 6.1 L
Bore/Stroke	4.65x5.51 inches 118 x 140 mm
Emissions	Tier IV
Rated Power (net)	133 hp 99.2 kW
Rated Power (gross)	141.4 hp 105.4 kW
Fuel system	common rail direct injection
Air cleaner	dual dry element
Rated RPM	2200
Starter	electric
Starter volts	12

Transmission

Transmission options
24-speed partial power shift
32-speed partial power shift

Transmission — Intelli-Shift

Transmission	Intelli-Shift
Type	partial power shift
Gears	24 forward and reverse
Clutch	electro-hydraulic wet disc
Eight power shift gears in three ranges, with electro-hydraulic shuttle.

Transmission — Intelli-Shift Creeper

Transmission	Intelli-Shift Creeper
Type	partial power shift
Gears	32 forward and reverse
Clutch	electro-hydraulic wet disc

Dimensions

Kubota M6-141 Tires
Standard tires (ag)	Front: 14.9R24. Rear: 18.4R38

Dimensions
Wheelbase	105.9 inches 268 cm
	105.5 inches*With optional front axle suspension. 267 cm
Length	171.7 inches 436 cm
	171.3 inches*With optional front axle suspension. 435 cm
Width	85.8 inches 217 cm
Height (cab)	113.2 inches 287 cm
Weight	10880 lbs 4935 kg
	11321 lbs*With optional front axle suspension. 5135 kg
Ground clearance	22.2 inches 56 cm
Front tread	69.9 to 73.8 inches 177 to 187 cm
Rear tread	62.6 to 82.3 inches 159 to 209 cm

Tests

OCED Tractor Test 2155
Diesel 24-speed 4WD June 1 - 16, 2016 Link: OCED Tractor Test 2155 file
PTO performance
Max power	126.58 hp 94.4 kW
Fuel use	7.3 gal/hour 27.6 l/hour
Power at rated engine speed	125.37 hp 93.5 kW
Fuel use	7.9 gal/hour 29.9 l/hour
Power at rated PTO speed	125.22 hp 93.4 kW
Fuel use	7.4 gal/hour 28.0 l/hour
Drawbar performance
Max power	106.08 hp 79.1 kW
Fuel use	7.8 gal/hour 29.5 l/hour
Max pull	10625 lbs 4819 kg

Photos

Kubota M6-141 tractor photo
