Lamborghini Sprint 674-75

The Lamborghini Sprint 674-75 is a tractor produced by Lamborghini. It is equipped with a 244.1 ci 4.0 L engine. The listed engine power is Diesel (listed): 72 hp / 53.7 kW. Transmission: Agroshift. Operating weight: 5490 to 6371 pounds.

Engine Power

Diesel (listed): 72 hp / 53.7 kW

Fuel & Capacities

23.8 gal 90.1 L

Transmission

Agroshift

Operating Weight

5490 to 6371 pounds

Overview

	2000 - 2004 Sprint SeriesUtility tractor Sprint Series Utility tractor

Production
Manufacturer	Lamborghini
Utility tractor

Lamborghini Sprint 674-75 Engine
SAME 4.0L 4-cyl diesel
Fuel tank	23.8 gal 90.1 L
Engine details ...

Lamborghini Sprint 674-75 Power
Engine	72 hp 53.7 kW

Mechanical
Two- or four-wheel drive
Power steering
Four-post ROPS. Cab optional.

Hydraulics
Pump flow	9.5 gpm 36.0 lpm

Tractor hitch
Rear Type	II
Rear lift	6394 lbs 2900 kg

Power Take-off (PTO)
Rear PTO	independent
Rear PTO Type	540/540E/1000

Dimensions & Tires
2WD Wheelbase	88 inches 223 cm
4WD Wheelbase	86.1 inches 218 cm
Weight	5490 to 6371 pounds
Front tire	7.50-18
2WD Rear tire	480/70R30
Full dimensions and tires ...

Electrical
Ground	negative
Battery volts	12

References

Sprint 654/55 - 664/65 - 674/75 - 684/85 published in 1999, by Lamborghini
Sprint 654/55 - 664/65 - 674/75 - 684/85 published in 2002, by Lamborghini

Engine

Engine Detail — 244.1 ci / 4.0 L Diesel

Manufacturer	SAME 1000.4WD
Fuel Type	Diesel
Configuration	4-cylinder, liquid-cooled
Displacement	244.1 ci 4.0 L
Bore/Stroke	4.134x4.55 inches 105 x 116 mm
Power	72 hp 53.7 kW
Rated RPM	2350
Torque	203.6 lb-ft 276.1 Nm
Torque RPM	1400
Starter	electric
Starter volts	12

Transmission

Transmission options
20-speed
24-speed
45-speed three-speed power shift

Transmission — 20 forward and 10 reverse

Gears

20 forward and 10 reverse

Transmission — 24 forward and 12 reverse

Gears	24 forward and 12 reverse
With 420/70R30 rear tires.

Transmission — Agroshift

Transmission	Agroshift
Type	three-speed power shift
Gears	45 forward and reverse

Dimensions

Lamborghini Sprint 674-75 Tires
2WD Standard tires (ag)	Front: 7.50-18. Rear: 480/70R30
4WD Standard tires (ag)	Front: 320/70R20. Rear: 480/70R30
2WD Optional tires (ag)	Front: 7.50-16. Rear: 420/70R30
2WD Optional tires (ag)	Front: 7.50-20. Rear: 13.6R36
4WD Optional tires (ag)	Front: 360/70R20. Rear: 420/70R30
4WD Optional tires (ag)	Front: 320/70R24. Rear: 13.6R36
4WD Optional tires (ag)	Front: 405/70R20. Rear: 540/65R28

Dimensions
2WD Wheelbase	88 inches 223 cm
4WD Wheelbase	86.1 inches 218 cm
Length	139 inches 353 cm
Width	75.6 inches 192 cm

Lamborghini Sprint 674-75 Weight
2WD ROPS	5490 lbs 2490 kg
2WD Cab	5864 lbs 2659 kg
4WD ROPS	5997 lbs 2720 kg
4WD Cab	6371 lbs 2889 kg

Lamborghini Sprint 674-75 Height
Steering wheel	67.7 inches 171 cm
Hood	59.5 inches 151 cm
ROPS	94.5 inches 240 cm
Cab	95.3 inches 242 cm

Photos

Lamborghini Sprint 674-75 tractor photo

Recommended Implements & Sizing Guide

Engineering recommendations for Lamborghini Sprint 674-75 based on its 72 HP power envelope and ASAE agricultural standards.

Implement & Operation	Recommended Size	Workload Rating	Engineering Notes
Moldboard PlowPrimary Tillage	3 to 4 Bottom (16")3 - 4 铧 (40 cm)	Heavy Duty	Suitable for medium loam and stubble turnover.
Rotary Cutter / MowerMowing & Clearing	7 to 8 ft (84-96 in)2.1 - 2.4 m	Heavy Duty	Heavy-duty twin spindle cutter for overgrown acreage.
Rotary TillerSeedbed Prep	78 to 84 in200 - 215 cm	Heavy Duty	Heavy commercial tiller with multi-speed gearbox.
Disc HarrowSecondary Tillage	7 to 8 ft Tandem Disc2.1 - 2.4 m 对开双排耙	Medium Duty	Field leveling and clod breaking behind plows.
Hay BalerHay & Forage	4x4 to 4x5 Round Baler1.2x1.5 m 紧凑圆捆机	Heavy Duty	Silage and dry hay; 540 RPM PTO with slip-clutch.

Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for Lamborghini Sprint 674-75.

Estimated Continuous Field Runtime: 6.4 hrs

Approximately 6.4 hours of continuous field operation at ~75% rated power on a full tank (23.8 gal / 90.1 L).

Estimated 75% Load Fuel Burn~3.7 gal/hr (14.2 L/hr)

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)

Standard Spec: API CK-4 / CJ-4 Heavy Duty

Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)

Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)

Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix

Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze

Service Interval: 2 Years / 1500 Hours
