Massey Ferguson 2925H

The Massey Ferguson 2925H is a tractor produced by Massey Ferguson Lawn Tractors. It is equipped with a 726 cc 44.3 ci engine. The rated power output is 25 hp 18.6 kW. Transmission: Sundstrand 15U. Operating weight: 690 lbs 312 kg.

Overview

	1998 - 2003 2900 SeriesGarden tractorSimplicity built
1998 - 2003
2900 Series
Garden tractor
Simplicity built

1998 - 2003
2900 Series
Garden tractor
Simplicity built

Series map: 2924D2925H24.5hp25.0hp

Note: the Massey Ferguson model 2925H is the same as the Simplicity Legacy 25. The following data is from the Legacy 25 listing.

Production
Distributor	Massey Ferguson
Manufacturer	Simplicity
Garden tractor
Built in Port Washington, Wisconsin, USA
Original price	$8,525 (1998 )
	$10,100 (2001 )

Massey Ferguson 2925H Engine
25HP Kohler 726cc 2-cyl gasoline
Fuel tank	6 gal 22.7 L
Engine details ...

Massey Ferguson 2925H Transmission
hydrostatic
Transmission details ...

Mechanical
Two-wheel drive
Final drives	spur gear
Differential lock	mechanical rear
Power steering
Disc brakes
Open operator station. Hard-side weather cab optional. Two-post ROPS available.

Hydraulics
Pressure	950 psi 65.5 bar
Pump flow	3 gpm 11.4 lpm

Tractor hitch
Rear Type	0 OptOptional
Rear lift	450 lbs 204 kg

Power Take-off (PTO)
Rear PTO	independent OptOptional
Clutch	electric
Rear PTO Type	540 (1.375)
	2000 (1.0)
Front PTO	independent
Clutch	electro-magnetic

Dimensions & Tires
Wheelbase	55 inches 139 cm
Weight	802 lbs 363 kg
Front tire	18x8.5-8
Rear tire	26x12-12
Full dimensions and tires ...

Electrical
Ground	negative
Charging system	alternator
Charging amps	15
Battery CCA	500
Battery volts	12

References
Lawn & Garden Equipment published in 1997, by Massey Ferguson
Lawn & Garden Equipment published in 1998, by Massey Ferguson
Lawn & Garden Equipment published in 1999, by Massey Ferguson
Lawn & Garden Equipment published in 2000, by Massey Ferguson*
Lawn & Garden Equipment published in 2002, by Massey Ferguson
Operator's Manual Legacy / 2000 / 2900 Series (1717573) published in 2003
2002 Product Specifications published by Simplicity
*Publication contains known errors.

Engine

	1998 - 2003 2900 SeriesGarden tractorSimplicity built
1998 - 2003
2900 Series
Garden tractor
Simplicity built

1998 - 2003
2900 Series
Garden tractor
Simplicity built

Series map: 2924D2925H24.5hp25.0hp

Note: the Massey Ferguson model 2925H is the same as the Simplicity Legacy 25. The following data is from the Legacy 25 listing.

Engine Detail — 726 cc / 44.3 ci Gasoline

Manufacturer	Kohler CH740
Fuel Type	Gasoline
Configuration	2-cylinder, air-cooled horizontal-shaft V-Twin
Displacement	726 cc 44.3 ci
Bore/Stroke	3.27x2.64 inches 83 x 67 mm
Power (gross)	25 hp 18.6 kW
Compression	9:1
Starter	electric
Starter volts	12
Oil capacity	2.1 qts 2.0 L

Massey Ferguson 2925H Engine
Image courtesy of Mark Salamack

Transmission

	1998 - 2003 2900 SeriesGarden tractorSimplicity built
1998 - 2003
2900 Series
Garden tractor
Simplicity built

1998 - 2003
2900 Series
Garden tractor
Simplicity built

Series map: 2924D2925H24.5hp25.0hp

Note: the Massey Ferguson model 2925H is the same as the Simplicity Legacy 25. The following data is from the Legacy 25 listing.

Transmission — Sundstrand 15U

Transmission	Sundstrand 15U
Type	shaft-driven hydrostatic
Gears	infinite forward and reverse (2-range)
Oil capacity	6 qts 5.7 L
Oil type	ATF F
Oil change	400 h
Sundstrand 15 hydrostatic with Peerless 2600 transaxle.

	ATF F

Dimensions

	1998 - 2003 2900 SeriesGarden tractorSimplicity built
1998 - 2003
2900 Series
Garden tractor
Simplicity built

1998 - 2003
2900 Series
Garden tractor
Simplicity built

Series map: 2924D2925H24.5hp25.0hp

Note: the Massey Ferguson model 2925H is the same as the Simplicity Legacy 25. The following data is from the Legacy 25 listing.

Massey Ferguson 2925H Tires
Lawn/turf front	18x8.5-8
Lawn/turf rear	26x12-12

Dimensions
Wheelbase	55 inches 139 cm
Length	78.75 inches 200 cm
Width	44.75 inches 113 cm
Height (steering wheel)	51 inches 129 cm
Height (ROPS)	76.5 inches 194 cm
Weight	802 lbs 363 kg
Max rear axle	1800 lbs 816 kg
Ground clearance	8 inches 20 cm
Rear axle	1.1875 inch diameter 30 mm

Attachments

	1998 - 2003 2900 SeriesGarden tractorSimplicity built
1998 - 2003
2900 Series
Garden tractor
Simplicity built

1998 - 2003
2900 Series
Garden tractor
Simplicity built

Series map: 2924D2925H24.5hp25.0hp

Note: the Massey Ferguson model 2925H is the same as the Simplicity Legacy 25. The following data is from the Legacy 25 listing.

Attachment overview
48" mid-mount mower deck
54" mid-mount mower deck
60" mid-mount mower deck
Snowblower
Blade
Front-end loader
Backhoe
Garden tractors are capable of using tillers, plows, or other ground-engaging attachments. TractorData does not list details of these attachments.

Kwik-Way Backhoe
Backhoe type	Kwik-Way Backhoe
Weight	690 lbs 312 kg
Transport height	85 inches 215 cm
Bucket width	9 inches 22 cm
	12 inches 30 cm
2-Foot flat digging depth	78 inches 198 cm
Reach from pivot	123 inches 312 cm
Loading height	84 inches 213 cm
Bucket Rotation	147°
Swing Arc	151°

Photos

Massey Ferguson 2925H tractor photo
