McCormick-Deering Super AWD-6

The McCormick-Deering Super AWD-6 is a tractor produced by Mccormick Deering. It is equipped with a 264 ci 4.3 L engine. Transmission: 5 forward and 1 reverse. Operating weight: 5768 to 7298 pounds.

Fuel & Capacities
17.5 gal 66.2 L
Transmission
5 forward and 1 reverse
Operating Weight
7,298 lbs 3310 kg

Overview

McCormick-Deering Super AWD-6 tractor photo
1953 - 1957 Standard-tread tractor
Production
Manufacturer
McCormick-Deering (a part of International Harvester)
Standard-tread tractor
Built in Melbourne, Australia
Variants
Super AW-6
kerosense engine, standard front
Super AWD-6
diesel engine, standard front
Super AM
kerosene engine, row-crop front
Super AMD
diesel engine, row-crop front
McCormick-Deering Super AWD-6 Engine
International Harvester 4.3L 4-cyl diesel
Fuel tank
17.5 gal 66.2 L
Engine details ...
McCormick-Deering Super AWD-6 Transmission
5-speed
Transmission details ...
McCormick-Deering Super AWD-6 Power
Mechanical
Two-wheel drive
Differential manual drum brakes
Open operator station.
Power Take-off (PTO)
Rear PTO
optional
Rear PTO Type
537
Dimensions & Tires
Wheelbase
76.5 inches 194 cm
Weight
5768 to 7298 pounds
Front tire
7.50-16
Rear tire
14x30
Full dimensions and tires ...
Belt Pulley
Diameter
11 inches 27 cm
Width
7.5 inches 19 cm
RPM
899
Speed
2588 ft/min 788.82 meters/min
References
Super AWD-6 references literature
International Harvester Australia: Geelong Works by Sarah Tomac*
International Harvester Tractors & Equipment in Australia & New Zealand by Graeme Quick
International Harvester Tractors & Equipment in Australia & New Zealand by Graeme Quick
*Publication contains known errors.

Engine

Engine Detail — 264 ci / 4.3 L Diesel

Manufacturer
International Harvester
Fuel Type
Diesel
Configuration
4-cylinder, liquid-cooled
The diesel on the Super AWD-6 used glow plugs for starting, unlike the gasoline starter of the US-built Super WD-6
Displacement
264 ci 4.3 L
Bore/Stroke
4.00x5.25 inches 102 x 133 mm
Rated RPM
1450
Starter type
electric
Oil capacity
6.4 qts 6.1 L
Coolant capacity
20 qts 18.9 L
Intake valve clearance
0.022 inches (hot) 0.559 mm
Exhaust valve clearance
0.022 inches (hot) 0.559 mm

Transmission

Transmission — 5 forward and 1 reverse

Gears
5 forward and 1 reverse
Oil capacity
41.6 qts 39.4 L
With 14x30 rear tires.
Super AWD-6 speeds

Dimensions

McCormick-Deering Super AWD-6 Tires
Ag front
7.50-16
Ag rear
14x30
Dimensions
Wheelbase
76.5 inches 194 cm
Length
125 inches 317 cm
Width
72.75 inches 184 cm
Height
70.75 inches (air cleaner) 179 cm
Height (exhaust)
91.5 inches 232 cm
Shipping weight
5,768 lbs 2616 kg
Operating weight
7,298 lbs 3310 kg
Ground clearance
15.1 inches (rear axle) 38 cm
Front tread
46.75 inches 118 cm
Rear tread
55 inches 139 cm

Photos

McCormick-Deering Super AWD-6 tractor photo

McCormick-Deering Super AWD-6 tractor photo

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for Mccormick Deering McCormick-Deering Super AWD-6.

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours

Mccormick Deering McCormick-Deering Super AWD-6 Specification Unit Converter

Convert power, fluid capacities, and operating weights between metric and imperial standards for Mccormick Deering McCormick-Deering Super AWD-6.

Converted Equivalents:

Horsepower (HP)0 hp
Kilowatts (kW)0 kW
Metric Horsepower (PS / CV)0 PS
