mccormick deering w 4

1939 - 1952

Standard-tread tractor

Standard-tread tractor

NTTL 342: distillate 5-speed 2WD

NTTL 353: gasoline 5-speed 2WD

Distillate 5-speed 2WD May 9 - 25, 1940 Link: Nebraska Tractor Test 342 file

Belt power (max)

23.11 hp 17.2 kW

Belt fuel use (max)

2.0 gal/hour 7.6 l/hour

Drawbar performance

Max power

21.38 hp 15.9 kW

Gear 2 used for power test.

Max pull

3,297 lbs 1495 kg

Gear 1 used for pull test.

Gasoline 5-speed 2WD September 16 - 20, 1940 Link: Nebraska Tractor Test 353 file

Belt power (max)

26.21 hp 19.5 kW

Belt fuel use (max)

2.3 gal/hour 8.7 l/hour

Drawbar performance

Max power

23.97 hp 17.9 kW

Gear 2 used for power test.

Max pull

3671 lbs 1665 kg

Gear 1 used for pull test.
