mccormick deering w 9
 | 1940 - 1953
Standard-tread tractor | 1940 - 1953 | Standard-tread tractor |
|---|---|---|---|
1940 - 1953 | |||
Standard-tread tractor | |||
1940 - 1953 | |
|---|---|
Standard-tread tractor |
Tractor Tests | |
|---|---|
NTTL 369: gasoline 5-speed 2WD | |
NTTL 371: distillate 5-speed 2WD |
Nebraska Tractor Test 369 | ||
|---|---|---|
 | | |
| ||
|
|---|
Nebraska Tractor Test 369 | |
|---|---|
Gasoline 5-speed 2WD
May 21 - June 17, 1941
Link: Nebraska Tractor Test 369 file | |
Belt power (max) | 49.40 hp
36.8 kW |
Belt fuel use (max) | 4.2 gal/hour
15.9 l/hour |
Drawbar performance | |
Max power | 44.15 hp
32.9 kW |
Gear 3 used for power test. | |
Max pull | 6,414 lbs
2909 kg |
Gear 1 used for pull test. | |
Nebraska Tractor Test 371 | ||
|---|---|---|
 | | |
| ||
|
|---|
Nebraska Tractor Test 371 | |
|---|---|
Distillate 5-speed 2WD
June 4 - 17, 1941
Link: Nebraska Tractor Test 371 file | |
Belt power (max) | 46.36 hp
34.6 kW |
Belt fuel use (max) | 4.3 gal/hour
16.3 l/hour |
Drawbar performance | |
Max power | 42.67 hp
31.8 kW |
Gear 3 used for power test. | |
Max pull | 6,577 lbs
2983 kg |
Gear 1 used for pull test. | |
