mccormick deering w 9

1940 - 1953

Standard-tread tractor

Standard-tread tractor

NTTL 369: gasoline 5-speed 2WD

NTTL 371: distillate 5-speed 2WD

Gasoline 5-speed 2WD May 21 - June 17, 1941 Link: Nebraska Tractor Test 369 file

Belt power (max)

49.40 hp 36.8 kW

Belt fuel use (max)

4.2 gal/hour 15.9 l/hour

Drawbar performance

Max power

44.15 hp 32.9 kW

Gear 3 used for power test.

Max pull

6,414 lbs 2909 kg

Gear 1 used for pull test.

Distillate 5-speed 2WD June 4 - 17, 1941 Link: Nebraska Tractor Test 371 file

Belt power (max)

46.36 hp 34.6 kW

Belt fuel use (max)

4.3 gal/hour 16.3 l/hour

Drawbar performance

Max power

42.67 hp 31.8 kW

Gear 3 used for power test.

Max pull

6,577 lbs 2983 kg

Gear 1 used for pull test.
