Mitsubishi R1500
The Mitsubishi R1500 is a tractor produced by Mitsubishi. It is equipped with a 46.4 ci 0.8 L engine. The rated power output is 14.8 hp 11.0 kW. Transmission: 5 forward and 1 reverse. Operating weight: 1323 lbs 600 kg.
Engine Power
14.8 hp
11.0 kW
Fuel & Capacities
Diesel
Transmission
5 forward and 1 reverse
Operating Weight
1323 lbs
600 kg
Mitsubishi R1500 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1970 - 1975
Compact Utility tractor |
|---|---|
1970 - 1975 | |
Compact Utility tractor | |
Production | |
|---|---|
Manufacturer | Mitsubishi |
Compact Utility tractor | |
Mitsubishi R1500 Engine | |
|---|---|
Mitsubishi 0.8L 1-cyl diesel | |
Engine details ...  |
Mitsubishi R1500 Transmission | |
|---|---|
5-speed gear | |
Transmission details ...  |
Mitsubishi R1500 Power | |
|---|---|
Engine | 14.8 hp
11.0 kW |
Mechanical | |
|---|---|
Two-wheel drive | |
Open operator station. |
Tractor hitch | |
|---|---|
Rear Type | I |
Power Take-off (PTO) | |
|---|---|
Rear PTO Type | 540/816 |
Dimensions & Tires | |
|---|---|
Wheelbase | 49.2 inches
124 cm |
Weight | 1323 lbs
600 kg |
Front tire | 4.00-12 |
Rear tire | 8-20 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
Farm Tractor R1500 published in 1969, by Mitsubishi | |
Farm Tractor R1500 published in 1969, by Mitsubishi |
Engine
Engine Detail — 46.4 ci / 0.8 L Diesel
Manufacturer | Mitsubishi SDT75 |
Fuel Type | Diesel |
Configuration | 1-cylinder, liquid-cooled |
Displacement | 46.4 ci
0.8 L |
Bore/Stroke | 3.78x4.13 inches
96 x 105 mm |
Power | 14.8 hp
11.0 kW |
Rated RPM | 2400 |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission — 5 forward and 1 reverse gear
Type | gear |
Gears | 5 forward and 1 reverse |
 | |
Dimensions
Mitsubishi R1500 Tires | |
|---|---|
Ag front | 4.00-12 |
Ag rear | 8-20 |
Dimensions | |
|---|---|
Wheelbase | 49.2 inches
124 cm |
Length | 79.7 inches
202 cm |
Width | 44.5 inches
113 cm |
Height | 48.8 inches
123 cm |
Weight | 1323 lbs
600 kg |
Ground clearance | 15.2 inches
38 cm |
Front tread | 31.5 inches
80 cm |
Rear tread | 30.7/36.4 inches
77/92 cm |
Photos
Mitsubishi R1500 tractor photo
